568 Contact & Infrared Temp Gun

Rugged, ergonomic design that stands up to tough industrial, electrical, & mechanical environments

Buy now!

$853.99CAD

Have questions? We're here to help!

Call

QTY

Used in

Fluke 568 two-in-one infrared and contact thermometer handles a wide temperature range

The Fluke 568 Infrared Thermometer is a combination contact and non-contact thermometer in one. It offers a wider temperature range than most other infrared thermometers while offering users more features controlled through an intuitive graphical display and menu. The simple, three-button on-screen menu interface (in 7 languages) is quick to use and makes even complex measurements easy. It takes just a few pushes of a button to adjust emissivity, record data, or turn on and off alarms. The 50:1 distance-to-spot ratio allows you to measure smaller objects from further away. And you can count on the rugged, ergonomic design to stand up to tough industrial, electrical, HVAC, and mechanical environments to help you work more efficiently in more applications.

• Contact and non-contact thermometer in one

• Measures temperatures from -40°C to 800°C (-40°F to 1472°F) accurate to +1.0°C or +1.0% of reading (whichever is greater)

• Features rugged, ergonomic design that stands up to tough industrial, electrical, and mechanical environments.

• Offers a distance-to-spot ratio of 50:1

• Works with most K-type thermocouples

Infrared Temperature Range	-40°C to 800°C (-40°F to 1472°F)
Infrared Accuracy	< 0°C (32°F): ±(1.0°C (±2.0°F) + 0.1°/1°C or°F) > 0°C (32°F): ±1% or ±1.0°C (±2.0°F), whichever is greater
Display Resolution	0.1°C / 0.1°F
Infrared Spectral Response	8 µm to 14 µm
Infrared Response Time	< 500 msec
Thermocouple Type-K Input Temperature Range	-270°C to 1372°C (-454°F to 2501°F)
Thermocouple Type-K Input Accuracy	-270°C to -40°C: ±(1°C + 0.2°/1°C) (-454°F to -40°F: ±(2°F + 0.2°/1°F)) -40°C to 1372°C: ±1% or 1°C (-40°F to 2501°F: ±1% or 2°F), whichever is greater
D:S (Distance to Measurement Spot Size)	50:1
Laser Sighting	Single-point laser < 1 mw output Class 2 (II) operation, 630 nm to 670 nm
Minimum Spot Size	19 mm (0.75 in)
Emissivity Adjustment	By built-in table of common materials or digitally adjustable from 0.10 to 1.00 by 0.01
Data Storage with Date/Time Stamp	99 points
PC Interface and Cable	USB 2.0 with FlukeView® Forms software
Hi/Low Alarms	Audible and two-color visual
Min/Max/Avg/Dif	Yes
Display	Dot matrix 98 x 96 pixels with function menus
Backlight	Two levels, normal and extra bright for darker environments
Trigger Lock	Yes
Switchable Celsius and Fahrenheit	Yes
Power	2 AA/LR6 Batteries and USB when used with a PC
Battery Life	If used continuously; Laser and backlight on,12 hours; Laser and backlight off, 100 hours
Operating Temperature Range	0°C to 50°C (32°F to 122°F)
Storage Temperature	-20°C to 60°C (-40°F to 140°F)
Bead Thermocouple Type-K Range	-40°C to 260°C (-40°F to 500°F)
Bead Thermocouple Type-K Accuracy	±1.1°C (2.0°F) from 0°C to 260°C (32°F to 500°F), typically within 1.1°C (2.0°F) from -40°C to 0°C (-40°F to 32°F)
