6020 High Temperature Calibration Oil Baths

Stable, uniform heat sources for calibrations up to 300°C

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

6020 High Temperature Calibration Oil Baths 01418

Comparison calibrations require a heat source that’s stable and uniform, and for moderately high temperatures nothing provides a better heat source than a Fluke Calibration oil bath.

Fluke Calibration oil baths are stable to +/- 0.001 °C and do not require calibration blocks or use of special calibration techniques to achieve that stability. The specifications of all our baths are “true specifications representing the performance you can expect to achieve in your lab under your operating conditions. Other companies advertise specs that they know you will never see in your lab. When their baths fail to perform, they blame it on you.

Fluke Calibration baths are built using a unique tank design that guarantees the best uniformity possible in a liquid bath. This, coupled with the industry’s best-selling digital bath controller, achieves uncompromised performance and ease of use.
You’ll love these baths, and once you’ve got one you’ll never buy anything else. There’s a bath to match any temperature range, depth, price, and performance you need.

• Large-capacity tanks for higher productivity
• Calibrations up to 300°C
• Built-in cooling coils for faster cooling
• Stability to +/- 0.001°C

Range	40°C - 300°C^†
Stability	+/- 0.001°C at 40°C (water) +/- 0.003°C at 100°C (oil 5012) +/- 0.005°C at 300°C (oil 5017)
Uniformity	+/- 0.002°C at 40°C (water) +/- 0.004°C at 100°C (oil 5012) +/- 0.012°C at 300°C (oil 5017)
Temperature Setting	Digital display with push-button data entry
Set-Point Resolution	0.01°C; High-resolution mode, 0.00018°C
Display Temperature Resolution	0.01°C
Digital Setting Accuracy	+/- 1°C
Digital Setting Repeatability	+/- 0.02°C
Heaters	350 and 1050 W
Access Opening	6020: 127 mm x 254 mm (5 in x 10 in) 6022: 127 mm x 254 mm (5 in x 10 in) 6024: 184 mm x 324 mm (7.25 in x 12.75 in)
Depth	6020: 305 mm (12 in) 6022: 464 mm (18.25 in) 6024: 337 mm (13.25 in)
Wetted Parts	304 Stainless Steel
Power	115 VAC (+/- 10%), 50/60 Hz, 10 A
Volume	6020: 27 L (7.2 gal) 6022: 42 L (11.2 gal) 6024: 42 L (11.2 gal)
Weight	6020: 32 kg (70 lb.) 6022: 36 kg (80 lb.) 6024: 36 kg (80 lb.)
Size (H x W x D)	6020: 648 mm x 406 mm x 508 mm (25.5 in x 16 in x 20 in) 6022: 813 mm x 406 mm x 508 mm (32 in x 16 in x 20 in) 6024: 699 mm x 483 mm x 584 mm (27.5 in x 19 in x 23 in)
Automation Package	MetTemp II software and RS-232 computer interface are included for setting bath temperature via remote computer. For IEEE-488, add the 2001-IEEE.
^†External cooling required for operation below 40°C
