Dwyer

668B/D Compact Differential Pressure Transmitters

Compact and lightweight, 0.8% FS accuracy, can withstand up to 15 PSIG overpressure with no damage to the unit

Starting At
$228.00 CAD
Normally ships in 2-3 Weeks

Configure   Request Quote

Can We Help You?

CALL US   EMAIL US   CHAT LIVE

Our product experts are here to help you find the right solution for your application!

Our low cost Series 668B/D Compact Differential Pressure Transmitters are capable of sensing differential gage pressure with ± 0.8% FS accuracy, and converts this pressure difference to a proportional high level analog output for both unidirectional and bi-directional pressure ranges. These transmitters can withstand up to 15 PSIG overpressure with no damage to the unit. The compact, lightweight design makes installation simple and easy. Units are protected against incorrect wiring, and include a protective terminal cover.

• Protection from 15 PSI overpressure & incorrect wiring
• High accuracy at low pressure ranges
• Two package selections allows easy device mounting to best fit application pressure connections

Service Air and non-conductive gases
Accuracy 0.8% FS
Temperature Limits Operating: 0F - 170F (-18C - 77C);
Storage: -40F - 185F (-40C - 85C)
Pressure Limits 15 PSIG (1.0 Bar)
Thermal Effects 0.03% FS/F ( 0.054% FS/C)
Compensated Range From 40F - 170F (4.4C * 77C)
Power Requirements 12 - 32 VDC
Output Signals 4 - 20 mA (2-wire), 0 - 10 VDC (3-wire), or 0 - 5 VDC (3-wire)
Zero Adjustment Accessible under the small terminal cover
Electrical Connection Terminal strip
Process Connection 3/16 in OD barbed brass for 1/8 in ID push-on tubing
Enclosure Stainless steel and PC+ABS alloy, UL 94 V-0 rated
Weight 4.0 oz (113 g)
Agency Approvals CE

• HVAC and VAV control
• Clean rooms and isolation rooms
• Duct static pressure measurement
