Starting at $5,472.59CAD
Configure
Fluke

718 Pressure Calibrators

Self-contained pressure calibrator provides a total pressure calibration solution for transmitters, gauges, and switches

Starting at
$5,472.59CAD
Have questions? We're here to help!
Have questions? We're here to help!
Configure
The complete solution to pressure calibration
The Fluke 718 Pressure Calibrator provides a total pressure calibration solution for transmitters, gauges, and switches. This compact pressure calibration solution is about a third of the size of comparable instruments and weighs just one kilogram (two pounds). The unique easy-to-clean pump helps protect it from damage and provides the ability to service the pump without disassembly, even in the field.

With an easy-to-use error % calculation you can make pass/fail decisions quickly. Meaning you can make decisions in the field without having to analyze the results later. The min/max/hold function also makes it easy to capture changing measurements for comparison or documentation. The integrated pressure switch test function, and best-in-class mA accuracy (0.015%) provide a high level of measurement confidence and even broader workload coverage.

Extend your pressure capabilities
The Fluke 718 Pressure Calibrator is available in 1, 30, 100, and 300 PSI ranges. It is also compatible with Fluke 750P Series Pressure Modules so you are certain to find a model that will meet your calibration needs.


• Pressure Source and mA Measurement to calibrate pressure devices
• Built-in pump for sourcing pressure to 300 PSI
• Easy-to-clean, field-serviceable, integrated pressure pump
• Built-in switch test for calibrating pressure switches
• Extend pressure capabilities by using Fluke 750P pressure modules


Measurement Accuracy



718 1G

718 30G

718 100G

718 300G

Pressure

Range

-1 PSI - 1 PSI

(-68.9 mbar - 68.9 mbar;

-6.89 kPa - 6.89 kPa)

-12 PSI - 30 PSI

(-850 mbar - 2 bar;

-85 kPa - 206.84 kPa)

-12 PSI - 100 PSI

(-850 mbar - 7 bar;

-85 kPa -.689.48 kPa)

-12 PSI - 300 PSI

(-850 mbar - 20 bar;

-85 kPa –- 2068.42 kPa)

Over Pressure

5x FS

5x FS

2x FS

375 PSI, 25 bar

Resolution

0.0001 PSI (0.001 mbar, 0.0001 kPa)

0.001 PSI (0.1 mbar, 0.01 kPa)

0.01 PSI (0.1 mbar, 0.01 kPa)

0.01 PSI (1 mbar, 0.1 kPa)

  • Thumbnail of document Data Sheet - 718 Pressure Calibrators
    Download

    Data Sheet - 718 Pressure Calibrators

    Download
  • Thumbnail of document Manual - 718 Pressure Calibrators
    Download

    Manual - 718 Pressure Calibrators

    Download
