725 Multifunction Process Calibrator

Measure & source mA, volts, temperature (RTDs & thermocouples), frequency, ohms, & pressure, using optional pressure modules

Buy now!

$5,886.99CAD

Have questions? We're here to help!

Call

QTY

Used in

Also found in

725 Multifunction Process Calibrator 03260

With the Fluke 725 Multifunction Process Calibrator you can easily source and measure almost any process parameter and test almost any process device. Measure and source mA, volts, temperature (RTDs and thermocouples), frequency, ohms, and pressure, using optional pressure modules.

From the moment you pick it up, the Fluke 725 is ready to perform as a powerful, yet easy-to-use field calibrator. Its simple controls, without menus, make operation easy and the backlit display provides better visibility in poor light. It features a small, streamline shape and a rugged, reliable design that make it ideal for standing up to harsh field conditions.

Versatile troubleshooting tool

Power transmitters during test using the loop supply with simultaneous mA measurement so you can test a transmitter out of circuit and better isolate problems. The 725 can also test a variety of fast pulsed RTD transmitters and PLCs (Programmable logic controllers), with pulses as short as 10 ms.

Source mA with simultaneous pressure measurement to conduct valve and I/P (Input current/Output pressure) tests in a single device. You can also test flow meters with frequency and CPM (counts per minute) functions and perform fast linearity tests with auto-step and auto-ramp features so you can quickly verify the mA signal at different output levels.

• Calibration of both temperature and pressure transmitters

• Measure/source/simulate mA loop parameters

• Measure and source mA, Volts DC, frequency, and resistance

• Built-in 24 V loop power supply

• Store and recall frequently used calibration set ups

Warranty	Three years
Voltage DC	30.000V: 0.02% + 2 counts (upper display) 30.000 V: 0.02% + 2 counts (lower display) 100.00 mV: 0.02% + 2 counts -10.00 mV to 75.00 mV: 0.025% + 1 count (via TC connector)
Current DC	24.000 mA: 0.02% + 2 counts
Resistance	0.0 to 400.0 Ω: 0.1 Ω (4-wire), 0.15 Ω (2- and 3-wire) 401 to 1500 Ω: 0.5 Ω (4-wire), 1 Ω (2- and 3-wire) 1500 to 3200 Ω: 1 Ω (4-wire), 1.5 Ω (2- and 3-wire)
Frequency	2.0 to 1000.0 CPM: 0.05% + 1 count 1.0 to 1100.0 Hz: 0.05% + 1 count 1.00 to 10.00 kHz: 0.05% + 1 count Sensitivity: 1 V peak-to-peak-minimum
Pressure	Accuracy from 0.025% of range using any of 29 pressure modules (for detailed specifications refer to pressure modules in options and accessories). Modules available for differential, gauge, vacuum, absolute, dual and high pressure.
Source Accuracy
Voltage DC	100.00 mV: 0.02% + 2 counts 10.000 V: 0.02% + 2 counts -10.00 mV to 75.00 mV: 0.025% + 1 count (via TC connector)
Current DC	24.000 mA (source): 0.02% + 2 counts 24.000 mA (simulate): 0.02% + 2 counts
Resistance	15.0 to 400.0 Ω: 0.15 Ω (exc. current 0.15 to 0.5 mA), 0.1 Ω (exc. current 0.5 to 2 mA) 401 to 1500 Ω: 0.5 Ω (excitation current 0.05 to 0.8 mA) 1500 to 3200 Ω: 1 Ω (excitation current 0.05 to 0.4 mA)
Frequency	2.0 to 1000.0 CPM: 0.05% 1.0 to 1100.0 Hz: 0.05%
