789 / 773 Process Meter and Clamp Meter Bundle Package
789 process meter and 773 clamp meter bundle package
The Fluke 789 ProcessMeter is the ultimate troubleshooting tool for electricians and instrumentation professionals, combining the functionality of a loop calibrator with the power of a digital multimeter. By equipping the 789 with a temperature measurement module and the wireless data logging capabilities of Fluke Connect with ShareLive™ video call (sold separately), process technicians can now do a lot more while carrying a lot less. And with its built-in, selectable 250 Ω HART resistor, it eliminates the need to carry a separate resistor with you.
If you need more time in your busy day take a good look at the Fluke 773 mA Clamp Meters. It’s designed to save you time, and money, by eliminating time wasting activities. Now you can troubleshoot and repair 4 - 20 mA loops without breaking the loop or bringing down the system. The Model 773 clamp meter measures mA signals for PLC and control system analog I/O and output signals from transmitters without breaking the loop. Source, simulate, and measure mA signals in the circuit as well as source and measure VDC. Feature a 4 - 20 mA in/out and scaled output. Provides loop power supply to power a transmitter. Features a detachable clamp with an extension cable to perform measurements in tight locations. Dual backlight display provides clear measurement presentation. Has a measurement spotlight to illuminate hard to see wires in dark enclosures. Automatic power off after 15 minutes, and automatic backlight and spotlight off after 2 minutes to save battery life.
789 ProcessMeter:
• Precision 1000 V, 440 mA True-RMS digital multimeter
• 24 V Loop power supply
• Very large dual display with enhanced backlight
• 1200 Ω drive capability on mA source
• HART mode setting with loop power and a built-in 250 Ω resistor
• 0% and 100 % buttons to toggle between 4 and 20 mA sourcing for a quick span check
• Externally accessible fuses for easy replacement
• Infrared-port to process data in FlukeView Forms (V2.1) software
• 0.1% Dc voltage accuracy and 0.05% DC current accuracy
• Frequency measurement to 20 kHz
• Min/Max/Average/Hold/Relative modes
• Diode Test and Continuity Beeper
• Simultaneous mA and % of scale readout
• Manual Step (100%, 25%, Coarse, Fine) plus Auto Step and Auto Ramp
• Externally accessible battery for easy battery changes
• Meets 1000 V EN61010-1 CAT III standards and 600 V EN61010-1 CAT IV standards
773 Milliamp Process Clamp Meter:
• Best in class 0.2 % accuracy
• 0.01 mA resolution and sensitivity
• Measure 4 - 20 mA signals without ”breaking the loop”
• Measure mA signals for PLC and control system analog I/O
• Dual backlit display with both mA measurement and percent of 4 - 20 mA span
• Measurement Spotlight illuminates hard to see wires in dark enclosures
• Detachable clamp with extension cable for measurements in tight locations
• Measure 10 - 50 mA signals in older control systems using the 99.9 mA range
• Automatically change the 4 - 20 mA output for remote testing
• Power saving features, auto-off, backlight timeout extend battery life
• Hold function captures and displays changing measurements
• Measure 4 - 20 mA signals with in-circuit measurement
• Simultaneous mA in-circuit measurement with 24 V loop power for powering and testing transmitters
• Source 4 - 20 mA signals for testing control system I/O or I/Ps
• mA output linear ramp or 25% step output
• Automatically change the 4 - 20 mA output for remote testing
• DC voltage measurement to verify 24 V power supplies or voltage I/O signals
• Source DC voltage to test input devices that accept a 1 - 5 V or 0 - 10 V signals
• Scaled mA output provides a continuous mA signal that corresponds to the 4 - 20 mA signal measured by the mA clamp
• Enables milliamp signal logging to a separate logging device without breaking the loop
• Output mA signal enables a logging DMM or other device to record the 4 - 20 mA signal without breaking the loop
• mA in/out: simultaneously measure the mA signal with the clamp and source a mA signal
• Apply a mA input signal to a device and measure its’ 4 - 20 mA output on devices such as valves or mA isolators
• Voltage output linear ramp or 25% step output
• Automatically change the voltage output for remote testing
789
Specifications | ||
Current Measurement | Range | 0 - 1 A AC or DC |
Resolution | 1 mA | |
Accuracy | 0.2% + 2 LSD (DC) | |
Range | 0 mA -30 mA | |
Resolution | 0.001 mA | |
Accuracy | 0.05% + 2 lSD | |
Current Sourcing | Range | 0-20 mA or 4 - 20 mA |
Resolution | 0.05% of span | |
Drive capability | 24 V compliance or 1200 Ω @ 20 mA | |
Frequency | To 19.999 kHz, 0.005% + 1 LSD | |
Continuity | Beeps for resistance < 100 Ω | |
Voltage Measurement | Range | 0 V - 1000 V AC (True-RMS) or DC |
Resolution | 0.1 mV - 1.0 V | |
Accuracy | 0.1% RDG + 1 LSD (VDC) | |
Resistance Measurement | To 40 MΩ, 0.2% + 1 LSD | |
Diode Test | 2.0 V shoes diode voltage drop | |
Display Current and % of Span | Yes | |
Auto Step, Auto Ramp | Yes | |
Environmental Specifications | ||
Operating Temperature | -20°C - 55°C | |
Storage Temperature | -40°C - 60°C | |
Humidity (Without Condensation) | 95% up to 30°C | |
Temperature Coefficient | 0.05 x (specified accuracy) per ºC (for temperatures < 18ºC or > 28ºC) | |
Safety Specifications | ||
Electrical Safety | Designed in accordance with IEC 1010-1, ANSI/ISA S82.01-1994 and CAN/CSA C22.2 No 1010.1-92 | |
Overvoltage Category | IEC 1010-1 CAT III 1000 V | |
Maximum Voltage | 1000 Vrms | |
Mechanical and General Specifications | ||
Size (H x W x L) | 50 mm x 100 mm x 203 mm (1.25 in x 3.41 in x 7.35 in) | |
Weight | 610 g (1.6 lbs) | |
Batteries | Four (4) AA alkaline batteries | |
Warranty | 3 years | |
Battery Life | 140 h typical (measurement), 10 h typical (sourcing 20 mA) | |
Shock and Vibration | Random, 2 g, 5 Hz - 500 Hz | |
773
Specifications | |||
Diameter of Measurable Conductor | 0.177 mm or 4.5 mm max. | ||
Temperature | Operating | -10°C - 50°C | |
Storage | -25°C - 60°C | ||
Operating Humidity | < 90% @ < 30°C, < 75% @ 30°C - 55°C | ||
Operating Altitude | 0 m - 2000 m | ||
IR Rating | IP 40 | ||
Size | 44 mm x 70 mm x 246 mm (2 7/8 in x 5 3/4 in x 11 5/8 in) | ||
Weight | 410 g (14.4 oz) | ||
Vibration | Random 2 g, 5 Hz - 500 Hz | ||
Shock | 1 m drop test (except the jaw) | ||
EMI/RFI | Meets EN61326-1 Note: For current measurement with JAW, add 1 mA to specification for EMC field strengths of 1 V/m up to 3 V/m. | ||
Temperature Coefficient | 0.01% °C (<18°C or > 28°C) | ||
Power / Battery Life | Four (4) AA 1.5 V Alkaline, IEC LR6, 3 12 h in mA source into 500 Ω | ||
mA Measurement (Measured by Clamp) | Resolution and Range | 0 mA - 20.99 mA | |
Accuracy | 0.2% + 5 counts | ||
Resolution and Range | 21.0 mA - 100.0 mA | ||
Accuracy | 1% + 5 counts | ||
mA Measurement (Measured in Series with Test Jacks) | Resolution and Range | 0 mA -24.00 mA | |
Accuracy | 0.2% + 2 counts | ||
mA Source (Maximum mA Drive: 24 mA into 1000 Ω) | Resolution and Range | 0 mA - 24.00 mA | |
Accuracy | 0.2% + 2 counts | ||
mA Simulate (Maximum Voltage 50 VDC) | Resolution and Range | 0 mA - 24.00 mA | |
Accuracy: | 0.2% + 2 counts | ||
Voltage Source (2 mA Maximum Drive Current) | Resolution and Range | 0 VDC - 10.00 VDC | |
Accuracy | 0.2% + 2 counts | ||
Voltage Measure | Resolution and Range | 0 VDC - 30.00 VDC | |
Accuracy | 0.2% + 2 counts | ||
Warranty | Three years for electronics One year for cable and clamp assembly | ||
| Fluke 789 / 773 Process Meter and Clamp Meter Bundle Package - Data sheet 1.9 MB |
$288.00 CAD
