8846A 6.5 Digit Precision Multimeters

6.5 digit precision multimeter, 24 ppm USB memory

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

8846 A 6 5 Digit Precision Multimeters 06795

The Fluke 8846A 6.5 digit multimeter features a unique dual display that allows you to measure two different parameters of the same signal from one test connection. To reveal signal quality issues like drift, intermittants, and stability, view data as a real-time trend plot or histogram, with the unique analyze mode. You won’t find graphical display capabilities like these on any other instrument in this class.

Patented split terminal jacks for the 2 x 4 ohms function allow you to perform 4-wire measurements using only two leads instead of four. A special test lead accessory is available to enable you to establish the connection. You get 6.5 digit resolution and accuracy plus the convenience and ease of using a single pair of leads.

Choose from several interfaces to connect the 8846A to a personal computer: serial, IEEE-488, and Ethernet come standard on both models. A USB device port is included on the 8846A meter for convenient data transfer to and from a PC via a portable USB storage device.

• 6.5 digit resolution
• Basic V dc accuracy of up to 0.0024 %
• Dual display
• 100 µA to 10 A current range, with up to 100 pA resolution
• Wide ohms ranges from 10 Ω to 1 GΩ with up to 10 µΩ resolution
• 2 x 4 ohms 4-wire measurement technique
• Measures frequency, capacitance, period, temperature (8846A)
• USB memory drive port (8846A)
• Fluke 45 and Agilent 34401A emulation
• Graphical display
• TrendplotTM paperless recorder mode, statistics, histogram
• CAT I 1000 V, The Fluke 8845A and 8846A 6.5 digit precision CAT II 600 V

Display	VFD Dot Matrix
Resolution	6.5 Digits
V DC	Ranges: 100 mV to 1000 V Maximum resolution: 100 nV Accuracy: 0.0035 + 0.0005
V AC	Ranges: 100 mV to 750 V Maximum resolution: 100 nV Accuracy: 0.06 + 0.03 Frequency: 3 Hz to 300 KHz
Resistance	2x4 Wire: Yes Ranges:100 Ω to 100 MΩ Maximum resolution: 100 µΩ Accuracy: 0.010 + 0.001
A DC	Ranges: 100 µA to 10 A Maximum resolution: 100 pA Accuracy: 0.050 + 0.005
A AC	Ranges: 10 mA to 10 A Maximum resolution: 10 µA Accuracy: 0.10 + 0.04 Frequency: 3 Hz to 10 kHz
Freq/period	Ranges: 3 Hz to 300 kHz Maximum resolution: 1 µHz Accuracy: 0.01 % Continuity/diode test: Yes
Capacitance	Ranges: 1 nF to 0.1 F Maximum resolution: 1 pf Accuracy: 1 %
Temperature	Type: Platinum RTD Range: -200 °C to +600 °C Maximum resolution:0.01 Accuracy:0.06
USB memory	USB memory drive port
Real time clock	Yes
Interfaces	RS-232, IEE-488.2, Ethernet, USB (with optional adapter)
Programming languages/modes	SCPI (IEEE-488.2), Agilent 34401A, Fluke 45
Weight	3.6 kg (8.0 lb)
Size (HxWxD)	88 mm x 217 mm x 297 mm (3.46 in x 8.56 in x 11.7 in)
Safety	Designed to comply with IEC 61010-1 2000-1, ANSI/ISA-S82.01-1994, CAN/CSA-C22.2 No. 1010.1-92 CAT I 1000 V, CAT II 600 V
Warranty	Three-year
