Precision when you need it for infrared temperature calibration
Whether you’re using in-line or handheld infrared pyrometers, you need good calibration standards to verify their accuracy. Our portable IR calibrators provide stable blackbody targets for calibrating noncontact IR thermometers from –30°C - 500°C.
These blackbody calibrator units feature a temperature controlled measurement surface with a diameter of 2.25 in (57 mm). The target temperature can be controlled in set-point increments of 0.1° from –30°C - 500°C and a well is located directly behind the blackbody surface for contact calibration.
For IR calibrations above normal ambient, the Fluke 9132 blackbody calibration source provides a stable measurement surface up to 500°C (932°F). Short heating and cooling times mean you won’t have to wait long to get your work done.
If you’re calibrating IR thermometers at cold temperatures, you’ll love our new Fluke 9133 blackbody calibration source. With solid-state cooling technology, this new IR calibrator reaches –30°C (22°F) in normal ambient conditions. With a conveniently located dry gas fitting on the front bezel, ice build up on the target can be avoided. At the upper end of its range, the Fluke 9133 provides stable temperatures to 160°C (320°F). With heating and cooling times of about 15 minutes from ambient to either extreme, the Fluke 9133 gets you to temperature quickly and performs when it gets there.
• Certify IR pyrometers from –30°C - 500°C (–22°F - 932°F)
• Large 57 mm (2.25 in) blackbody target
• RTD reference well for contact temperature measurement
• Small, compact design in a blackbody calibrator
9133 | 9132 | |
Temperature Range | -30°C - 150°C at 23°C ambient | 50°C - 500°C |
Accuracy | +/- 0.4°C (+/- 0.72°F) | +/- 0.5°C at 100°C |
Stability | +/- 0.1°C (+/- 0.18°F) | +/- 0.1°C at 100°C |
Target Size | 57 mm (2.25 in) | |
Target Emissivity | 0.95 (+/- 0.02 from 8 to 14 µm) | |
Resolution | 0.1 ° | |
Heating Time | 15 min (25°C to 150°C) | 30 min (50°C to 500°C) |
Cooling Time | 15 min (25°C to -20°C) | 30 min (500°C to 100°C) |
Computer Interface | RS-232 I/O included with 9930 Interface-it software | |
Power | 115 VAC (+/- 10%), 1.5 A, or | 115 VAC (+/- 10%), 3 A or |
Size (H x W x D) | 152 mm x 286 mm x 267 mm | 102 mm x 152 mm x 178 mm |
Weight | 4.6 kg (10 lb) | 1.8 kg (4 lb) |
NIST-Traceable | Data at -30°C, 0°C, 25°C, 75°C, 100°C, 125°C, and 150°C | Data at 50°C, 100°C, 200°C, 250°C, 300°C, 400°C, and 500°C |
