D1400 RTD Input Modules

Converts RTD temp. sensor input signals, linearizes the digital data, scales in degrees C/F & communicates the values to a host computer or PLC

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Also found in
D1400 RTD Input Modules 00595

The D1400 ADC module converts RTD temperature sensor input signals to digital information, linearizes the digital data, scales in either degrees C or F, and communicates the values to a host computer or PLC. The data values are transmitted in ASCII  to a host computer via RS232 or RS485 .

The D1400 series modules can also be mounted on a DIN-Rail using the MK-1 mounting kit.

Input ProtectionTo 120 VAC
Measurement Ranges0.00385, -200 to +850°C
0.00388, -100 to +125°C
0.00392, -200 to +600°C
RTD Types0.00385, 0.00388, 0.00392
Accuracy+/-0.3°C
Resolution0.1°(C or F)
Common Mode Rejection100 db at 50/60 Hz
User Selectable DegreesC or F scaling
Input Connections2,3, or 4 wire
Excitation Current0.25 mA
Max Lead Resistance50 Ω
