DFS 5.1 Doppler Flow Switch

Flow control from the outside of metal or plastic pipes

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

Call

Used in

Flow switches are particularly useful for pump protection or to activate flow or no-flow alarms. The DFS 5.1 Doppler Flow Switch is designed to give basic process control for pipe flow measurement, recommended for difficult liquids including wastewater, cooling water, slurries, sludge, chemicals, viscous liquids, and abrasives that would usually damage contacting Doppler flow switches. The non-contacting ultrasonic sensor mounts to the outside of metal or plastic pipes, without the need to cut the pipe or shut down the flow of your process, increasing your efficiency and ultimate profitability. With no maintenance required for the Doppler flow switch, it works on any pipe diameter 12.5 mm (0.5 in) or larger and installs in just minutes.

The relays in the DFS 5.1 can be set to turn ON and OFF at any flow rate between 0.075 m/s to 3 m/s (0.25 ft/s and 9.8 ft/s) in addition, the end-user could inset two links for separate ON/OFF set points or just one link for a high or low flow alarm.

• Flow Control from the Outside of Metal or Plastic Pipes
• 5 amp DPDT Control Relay
• Adjustable ON/OFF Set-Points
• Hi or Lo Flow Alarm Mode
• Adjustable Time Delay
• Relay Status LED
• Flow Rate LED bar graph

General Specifications
Spec name:	Description:
Enclosure	NEMA4X (IP 67) polycarbonate with a clear shatter-proof face
Power Input	100-240 V AC 50/60 Hz (±10%), 2 W
Control Relay	5 A DPDT
Set Points	ON/OFF adjustment from 0.075 m/s to 3 m/s (0.25 ft/s to 10 ft/s)
Pipe Size	Any pipe ID from 12.5 mm to 4.5 m (0.5 in to 180 in)
Operating Temperature (Electronics)	-23 °C to 60 °C (-10 °F to 140 °F)
Accuracy	±2%, requires solids or bubbles minimum size of 100 microns, minimum concentration 75 ppm. Repeatability: ±0.1%
Shipping Weight	3.6 kg (8 lbs)

Sensor Specifications
Spec name:	Description:
Model	Single-head ultrasonic with 6 m (20 ft) shielded cable
Operating Temperature (Sensor)	-40 °C to 150 °C (-40 °F to 300 °F)
