DHC Digihelic Differential Press. Controller

In Stock *

A 3-in-1 instrument possessing a digital display gage, control relay switches, and a transmitter with both current and voltage outputs

Starting at

$935.78CAD

Some configurations are in stock for immediate delivery!

Have questions? We're here to help!

Call

Configure

Used in

DHC Digihelic Differential Press Controller 08523

The Series DHC Digihelic® Differential Pressure Controller is a 3-in-1 instrument possessing a digital display gage, control relay switches, and a transmitter with both current and voltage outputs. Combining these 3 features allows the reduction of several instruments with one product, saving inventory, installation time, and cost. The Series DHC Digihelic® differential pressure controller is the ideal instrument for pressure, velocity, and volumetric flow applications reading in several commonly used engineering units with optional unidirectional or bidirectional ranges. These units achieve a 1.5% or better accuracy on extremely low ranges, and 0.5% accuracy for ranges at or above 1 in w.c. Calibration can be performed in the field, making maintaining its accuracy more manageable. Additionally, the Series DHC Digihelic® differential pressure controller includes 2 SPDT control relays with adjustable deadbands. Programming the unit is simple using the built-in menu. With scalable 4-20 mA, selectable voltage process outputs, and selectable Modbus® or BACnet communication, this controller can easily fit into your application.

• One instrument saves inventory, installation time, and money with its measurement versatility and innovative 3-in-1 design

• Measurement precision via full-scale accuracy of 1.5% or better on extremely low ranges, and 0.5% for ranges at or above 1 in w.c.

• Safe and secure with security menu programming

• Simplified field upgrade to DHC pressure controller with optional stainless steel bezel

Power Consumption	3 VA max.
Output Signals	4-20 mA (4-wire); 0-10 V, 0-5 V, 1-5 V, and 2-10 V (4-wire).
Communication	BACnet MS/TP or Modbus® RTU.
Supported Baud Rate	9600, 19200, 38400, 57600, 76800, 115200.
Device Load	1/8 unit load.
Zero and Span Adjustments	Accessible via menus.
Response Time	400 ms (damping set to 0).
Display	Backlit LCD display, LED setpoint indicators.
Electrical Connections	15 pin male high density D-sub connection. 18" (46 cm) cable with 15 conductors included.
Process Connections	1/8" female NPT ports on side and back.
Enclosure Rating	NEMA 4X (IP66).
Mounting Orientation	Not position sensitive.
Size	5" OD (127 mm) x 1.9" (48 mm) deep.
Weight	8.8 oz (250 g).
Compliance	BTL, CE.
Switch Specifications
Switch Type	2 SPDT relays.
Electrical Rating	1 A @ 30 VAC/VDC.
Set Point Adjustment	Accessible via menus.
Service	Air and non-combustible, compatible gases.
Wetted Materials	Consult factory.
Housing Material	Polycarbonate.
Accuracy:	±0.5% FSO for all ranges, except 0.5 in w.c. @ ±1% FSO, and ranges at or below ±0.25 in w.c. @ ±1.5% FSO.
Stability	< ±1% / year FSO.
Pressure Limits	Ranges > 1 in w.c.: 6 psi max operation, 6 psi burst; Ranges ≤ 1 in w.c.: 3.6 psi max operation, 6 psi burst.
Temperature Limits	-4 to 158°F (-20 to 70°C).
Thermal Effects	.02% FS / °F (.036% FS / °C).
Power Requirements	12-28 VDC or 12-28 VAC 50 to 400 Hz.
