Starting at $1,540.73CAD
Configure
Dwyer

DLI LCD Data Logger

Front Keypad, Wall Mountable, Remote Readings

Starting at
$1,540.73CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
DLI LCD Data Logger 09475
DLI LCD Data Logger af687
DLI LCD Data Logger cc3a6

 The Series DLI LCD Data Logger gives instant remote readings of temperature, humidity, or atmospheric pressure. The large, back-lit LCD and 8-button keypad provide convenient access to current data and recorder setup as well as memory and battery levels. The wall-mountable data logger can store at least 87,000 readings per channel. The easy to use DL700 software makes creating permanent records, performing data calculations, and graphing of data simple. The DLI can easily be started and stopped from a PC or delayed to start up to six months in advance. It can also stop recording at a specified time or after a certain number of readings have been taken.

Agency ApprovalsCE, model DLI-R not CE approved.
Weight16 oz (440 g).
HousingBlack anodized aluminum case.
InterfaceUSB port (interface cable required).
Battery Life1 yr with display off, 30 days with continuous display usage (approx).
Power Requirements9 V lithium metal battery, installed functional, user replaceable. Optional AC adapter.
Computer RequirementsWindows® 95, Windows ® 98, Windows® 2000, Windows ® ME, Windows NT®, and Windows ® XP operating system, one free USB port.
Sampling RateSelectable from 2 s to 24 hrs.
Sampling MethodStop on memory full or continuous recording.
Memory Size174,762 readings (DLI-R), 131,071 readings per channel (DLI-T, DLI-H) and 87,381 readings per channel (DLI-P).
Temperature/Humidity/Pressure SensorRange: -4 to 140°F (-20 to 60°C), 0 to 95% RH, 0 to 30 psia; Accuracy: ±0.9°F (±0.5°C), ±3% RH, ±1.0% FSR @ 77°F (25°C); Resolution: 0.1°F (0.05°C), 0.1% RH, 0.002 psia.
Temperature/Humidity SensorRange: -4 to 140°F (-20 to 60°C), 0 to 95% RH; Accuracy: ±0.9°F (±0.5°C) for 32 to 122°F (0 to 50°C), 3% RH; Resolution: 0.2°F (0.1°C), 0.1% RH.
Thermocouple SensorInternal range: -4 to 140°F (-20 to 60°C); Accuracy: ±0.9°F (±0.5°C) internally and for types J, K, T, E, and N, ±3°F (±2°C) for types R, S, and B; Resolution: 0.2°F (0.1°C) internally and for types J, K, T, E, and N, 0.9°F (0.5°C) for types R, S, and B.
RTD SensorRange: -328 to 1562°F (-200 to 850°C); Probe accuracy: ±0.09°F (±0.05°C) for -328 to 500°F (-200 to 260°C), ±0.5°F (±0.3°C) for 500 to 1562°F (260 to 850°C); Resolution: 0.01°F (0.01°C).
  • Thumbnail of document Data Sheet - DLI LCD Data Logger
    Download

    Data Sheet - DLI LCD Data Logger

    Download
  • Thumbnail of document Manual - DLI LCD Data Logger
    Download

    Manual - DLI LCD Data Logger

    Download
