Easidew PRO I.S. Dew Point Transmitter
Compact mechanical design minimizes installation time & provides a robust & reliable transmitter for I.S. hygrometer applications
The Easidew PRO I.S. dew-point sensor is designed to reliably and accurately measure dew point or moisture content in a wide variety of gas or liquid analyzer applications. The compact mechanical design minimises installation time and provides a robust and reliable transmitter for all global intrinsically safe hygrometer applications. The Easidew sensor can be used in combination with several of Michell’s moisture meters or moisture analyzers.
Applications:
• Moisture in natural gas production and processing
• Pipeline drying
• On line fiscal metering of gas
• Dew-Point measurement in LNG production processing
• Petrochemical process liquids
• Trace humidity measurement in polymer production
• Moisture analysis in CNG drying
• Dew Points in I.S. areas
• Measurement range –110 to +20°Cdp
• ATEX, IECEx, CCSAUS, FM, TC TR Ex certifi ed
• Accuracy ±1°Cdp
• 2-wire 4–20 mA output
• Traceable 13-point calibration certifi cate
• 450 barg pressure rating
• Alternative process connections available
• Material certifi cation to BS EN 10204 3.1
• Moisture in gases and liquids
• Service exchange program
• Oxygen Service cleaned
Accessories
![EPR SC Sensor Connector 05594]()
Michell InstrumentsEPR-SC Sensor Connector
Sensor connector for dew point transmitter
Call Today!
800-567-8686Normally ships in 4-6 weeks![EPR BRK Wall Mounting Bracket 05595]()
Michell InstrumentsEPR-BRK Wall Mounting Bracket
Wall mounting bracket for Easidew PRO I.S.
Call Today!
800-567-8686Normally ships in 3-4 weeks![CEA M20 NPT B Cable Entry Adapter 05596]()
Michell InstrumentsCEA-M20-NPT-B Cable Entry Adapter
M20 to 1/2" NPT, brass cable entry adapter
Call Today!
800-567-8686Normally ships in 3-4 weeks![CEA M20 NPT SS Cable Entry Adapter 05597]()
Michell InstrumentsCEA-M20-NPT-SS Cable Entry Adapter
M20 to 1/2" NPT, SS cable entry adaptor
Call Today!
800-567-8686Normally ships in 3-4 weeks![CEA M20 BSP B Cable Entry Adapter 05598]()
Michell InstrumentsCEA-M20-BSP-B Cable Entry Adapter
M20 to 1/2" BSP, brass cable entry adaptor
Call Today!
800-567-8686Normally ships in 3-4 weeks![CEA M20 BSP SS Cable Entry Adapter 05599]()
Michell InstrumentsCEA-M20-BSP-SS Cable Entry Adapter
M20 to 1/2" BSP, SS cable entry adaptor
Call Today!
800-567-8686Normally ships in 3-4 weeks![CG M20 B Hazardous Area Cable Gland 05600]()
Michell InstrumentsCG-M20-B Hazardous Area Cable Gland
Brass,ø3-8mm hazardous area cable gland
Call Today!
800-567-8686Normally ships in 3-4 weeks![CG M20 SS Hazardous Area Cable Gland 05601]()
Michell InstrumentsCG-M20-SS Hazardous Area Cable Gland
SS ø3-8mm hazardous area cable gland
Call Today!
800-567-8686Normally ships in 3-4 weeks![APT PAN Adapter 05544]()
Michell InstrumentsAPT-PAN Adapter
3/4" UNF to 5/8" UNF adapter
Call Today!
800-567-8686Normally ships in 2-3 weeks![APT GEI Adapter 05545]()
Michell InstrumentsAPT-GEI Adapter
G 1/2" BSP to 5/8" UNF adapter
Call Today!
800-567-8686Normally ships in 2-3 weeks![APT TSO Adapter 05546]()
Michell InstrumentsAPT-TSO Adapter
1/2" NPT to 5/8" UNF adapter
Call Today!
800-567-8686Normally ships in 2-3 weeks![CSB Sample Block 05547]()
Michell InstrumentsCSB Sample Block
5/8" SS sample block with 1/8" NPT inlet & outlet ports
Call Today!
800-567-8686Normally ships in 2-3 weeks![SSG SS Sintered Guard 05538]()
Michell InstrumentsSSG SS Sintered Guard
SS sintered guard replacement for protection against fine particulates <80µm
Call Today!
800-567-8686Normally ships in 4-6 weeks![GEN LABEL Transmitter Labels 05540]()
Michell InstrumentsGEN-LABEL Transmitter Labels
Additional/replacement transmitter labels (price per 2 off labels)
Call Today!
800-567-8686Normally ships in 2-3 weeks![BS 58 PK5 58 Bonded Seal 05541]()
Michell InstrumentsBS-58-PK5 5/8" Bonded Seal
5/8" Bonded Seal for process connection-pack of 5
Call Today!
800-567-8686Normally ships in 2-3 weeks![GI PF 01 Galvanic Isolator 05626]()
Michell InstrumentsGI-PF-01 Galvanic Isolator
KFD0-CS-EX1.50P galvanic isolator for Pura-IS-2W - Pepperl & Fuchs
This product is no longer available. Contact us at 800-567-8686 for alternative solutions.![LDI BRK Wall Mounting Bracket 05503]()
Michell InstrumentsLDI-BRK Wall Mounting Bracket
Wall mounting bracket for Easidew PRO I.S.
Call Today!
800-567-8686Normally ships in 4-6 weeks![EAU CK Easidew Pura Universal Comms Kit 05555]()
Michell InstrumentsEAU-CK Easidew & Pura Universal Comms Kit
Easidew & Pura Universal Comms Kit
Call Today!
800-567-8686Normally ships in 2-3 weeks![APT 002 Adapter 05559]()
Michell InstrumentsAPT-002 Adapter
3/4" MNPT to 5/8" UNF Male Adapter, SS
Call Today!
800-567-8686Normally ships in 2-3 weeks![EPD Intrinsically Safe Field Display 05606]()
Michell InstrumentsEPD Intrinsically Safe Field Display
4-digit loop-powered local monitor for the Easidew PRO I.S. and Easidew I.S. transmitters
Call Today!
800-567-8686Normally ships in 4-6 weeks
