HC2A-S Humidity Probe
Most versatile probe from ROTRONIC and forms the basis of the product portfolio, offering ±0.8 %rh and ±0.1 K accuracy
The standard Rotronic Humidity and Temperature probes can be used in application with temperature from -50…100°C / 0…100 % RH. With an outstanding accuracy ± 0.8% RH ±0.1°C. For calibration the probes can be replaced without almost any downtime. Together with a Rotronic HF5, PF4/5 transmitter or HP32 and HP23 this probe is the first selection for many applications. Versatile Humidity Probe HC2A-S The HC2A-S are the most sold versatile probes from Rotronic and form the basis of the product portfolio. They measure humidity and temperature and calculate the dew/frost point. Applications for the Humidity Sensors HC2A-S Both humidity sensors are used for HVAC, food industry building services equipment, paper, textile and pharmaceutical industries.
| Probe type | Standard black probe |
| Operating range | -50…100 °C / 0…100 %rh |
| Accuracy w. adjustment profile "standard" | ±0.8 %RH / ±0.1 K, at 10...30 °C; Adjustment at 23 °C and 10, 35, 80 %RH |
| Accuracy w. adjustment profile "high precision" | ±0.5 %RH / ±0.1 K, at 10...30 °C at 23 °C and 10, 20, 30, 40, 50, 60, 70, 80, 90 %RH |
| Power supply/Power consumption | 3.3…5 VDC |
| Current consumption | 4.5 mA at 3.3 VDC |
| Long-term stability | <1 %rh / year |
| Humidity sensor | Hygromer HT-1 |
| Temperature sensor | PT100 1/3 DIN Class B |
| Probe protection | Polycarbonate plastic cage, black |
| Filter cartridge | Polyethylene |
| Filter type | Polyethylene, 40 μm |
| Response time T 63 | <15 sec. |
| Allowed wind speed | 20 m/s, with filter |
| Psychrometric calculations | Dew or frost point |
| Reproducibility airchip | <0.02 %rh / 0.01 K |
| Exploitation software | ROTRONIC HW4 |
| Probe adjustment by software | 1 Point & multipoint %rh & °C |
| Firmware update | With internet and HW4 software |
| User information | From Software HW4 (devicemanager) |
| Data processing via HW4 | With interface cables |
| Device protection by password | Yes |
| Type of output signals | 2 x 0…1 VDC |
| Analogue outputs scaleable by the user | Yes |
| Analog output signal (standard) | 0…1 V = 0…100 %rh; 0…1 V = -40…60 °C |
| Digital output signal (standard) | UART |
| Service interface | UART |
| Reverse voltage protection | Mechanically in the connector |
| Max. cable length | Up to 5 m with passive cable. Up to 100 m with active cable |
| Probe material | PEEK |
| Enclosure material | Polycarbonate |
| Housing | Polycarbonate |
| FDA/GAMP compatibility | FDA 21 CFR Part 11 and GAMP compatible |
| Dimensions | Ø15 x 108 mm |
| Weight | 10 g |
• Pharmaceutical industries
