HHT Hazardous Area Humidity/Temperature Transmitter

FM approved explosion-proof and intrinsically safe models, replaceable calibrated sensor and integral LCD option

Starting at

$2,282.33CAD

Have questions? We're here to help!

Call

Configure

Used in

HHT Hazardous Area Humidity Temperature Transmitter 02347

HHT Hazardous Area Humidity Temperature Transmitter ecbe7

The Series HHT Hazardous Area Humidity/Temperature Transmitter takes accurate measurements in the harshest of environments. The explosion-proof model is offered with 4 to 20 mA output for humidity only. The intrinsically safe version is offered with 4 to 20 mA output for humidity and temperature, and do require an intrinsically safe barrier to meet hazardous area approvals.

• FM approved explosion-proof and intrinsically safe models
• Integral LCD option
• Dual temperature and relative humidity output models

Relative Humidity Range	0 to 100% RH
Temperature Range	-40 to 140°F (-40 to 60°C)
Accuracy	±2% 10 to 90% RH, ±0.9°F at 72°F (±0.3°C at 25°C)
Hysteresis	±1%
Repeatability	±0.1% typical
Temperature Limits	-40 to 140°F (-40 to 60°C)
Storage Temperature	-40 to 176°F (-40 to 80°C)
Compensated Temperature	-40 to 140°F (-40 to 60°C)
Power Requirements	For instrinsically safe models HHT-IX, 9.5 to 28 VDC. For explosion-proof models HHT-EX, 16.5 to 28 VDC
Output Signal	4 to 20 mA, 2 channels for humidity/temperature models (loop power on RH)
Response Time	15 seconds
Electrical Connections	Screw terminal block
Conduit Connection	1/2" female NPT
Drift	<1% RH/year
RH Sensor	Capacitance polymer
Temperature Sensor	Solid state band gap
Housing Material	Aluminum
Display	Optional 2 line alpha numeric, 8 characters/line. Temperature display is °F/°C selectable
Display Resolution	RH: 0.1%; Temperature: 0.1°F (0.1°C)
Weight	2 lb 8 oz (1134 g)
Enclosure Rating	NEMA 4X (IP66). Models HHT-EX: FM Explosion-proof, Class I Div. 1 Group B, C, D, Class II Div. 1 Group E, F, G, Class III Div. 1; Models HHT-IX: FM Instrinsically Safe, Class I Div. 1 Group A, B, C, D, Class II Div. 1 Group E, F, G, Class III Div. 1 T4
Agency Approvals	FM, CE

• Process monitoring
• Offshore HVAC monitoring
• Dust and grain handling
