HiTemp140X2 High Temperature Dual Probe Data Logger

Dual probe data loggers that feature ambient & remote Temp. probe combinations w/ extreme flexibility for high Temp. monitoring applications

Starting at

$1,168.50CAD

Have questions? We're here to help!

Call

Configure

Used in

Hi Temp140 X2 High Temperature Dual Probe Data Logger 01849

The HiTemp140X2 series of dual probe high temperature data loggers are comprised of a stainless steel data logger body that feature a combination of two remote temperature probes or one ambient and one remote temperature probe combination, offering extreme flexibility for high temperature monitoring applications. This product line is ideal for applications such as oven mapping, surface temperature monitoring, autoclave validation, sterilization processes, food processing applications and much more.

The HiTemp140X2-TD data logger models all feature a 2 in rigid, fast response, transitional diameter probe (TD) to measure ambient temperature, combined with a second bendable stainless steel probe (PT) or a flexible RTD probe (FP) option. The rigid 2 in TD probe is made of stainless steel, offers an ultra-fast response time and is suitable for measuring ambient temperatures in the harshest environments. The stainless steel PT probe options provide the ability to retain shape when bent into position and the sharp probe tip allows for easy insertion. The stainless steel PT probes also offer an extended measurement range to accommodate extremely high temperatures.

The HiTemp140X2-FP data logger models feature a lightweight, flexible RTD probe (FP) available in four lengths, combined with a 24 in bendable probe (PT) made of stainless steel with either a 1 in or 5 in probe sheath at the tip, or also available with 2 flexible RTD probes (FP). The flexible FP probe design allows the probe to be easily maneuvered and is ideal for temperature monitoring inside test tubes, small vials, and other delicate applications or tight spaces. The narrow thermistor probe tip on the FP is compatible for use with the MicroDisc probe attachment, allowing for precise surface temperature monitoring of shelving and more.

All HiTemp140X2 data loggers have the capacity to store up to 32,700 time and date stamped readings and feature non-volatile solid state memory that will retain data even if the battery becomes discharged. The HiTemp140X2 data logger series is compatible with the latest version of the MadgeTech Software. This allows for simple starting, stopping and downloading of collected data. Once the readings have been downloaded to the software, it can be viewed in graphic, tabular, and summary form for easy analysis, as well as the potential to be exported into Excel for further calculations.

• ± 0.1°C (± 0.18°F) accuracy
• Flexible probe measures from -60°C - 260°C (-76°F - 500°F)
• Bendable probe measures from -200°C - 350°C (-328°F - 662°F)
• Rigid probe measures from -200°C - 260°C (-328°F - 500°F)
• Submersible (IP68)
• User-replaceable battery
• Trigger settings
• Programmable start and stop time
• Battery life indicator

Temperature Sensor	RTD Probe (Rigid, Bendable and Flexible styles available)
Temperature Resolution	0.01 °C (0.018 °F)
Temperature Calibrated Accuracy	±0.1 °C (0.18 °F)
Probe Temperature Range	Rigid Probe: -200 °C to +260 °C (-328 °F to +500 °F) Bendable Probe: -200 °C to +350 °C (-328 °F to +662 °F) Flexible Probe: -60 °C to +260 °C (-76 °F to +500 °F)
Memory	32,767 readings
Reading Rate	1 reading every 1 seconds up to 1 reading every 24 hours
Baud Rate	125,000
Battery Life	1 year typical (1 minute reading rate at 25 °C / 77 °F) User Replaceable Battery
Material	Body: 316 Stainless Steel Rigid/Bendable Probe: 316 Stainless Steel Flexible Probe: PFA Insulated Cable
Dimensions	Body: 1.89 in x 0.97 in x 0.97 in (48 mm x 24.6 mm x 24.6 mm) Probes: TD: 2.0 in x 0.125 in dia. with 0.188 in transitional dia. (51 mm x 3.2 mm dia. with 4.8 mm transitional dia.) PT-1: Probe Tip: 1.7 in x 0.125 in dia. (42 mm x 3.2 mm dia.), Bendable Portion: 22 in x 0.062 in dia. (559 mm x 1.6 mm dia.) PT-5: Probe Tip: 4.8 in x 0.125 in dia. with 1 in x 0.188 dia. handle (121 mm x 3.2 mm dia. with 25 mm x 4.8 mm dia. handle), Bendable Portion: 22 in x 0.062 in dia. (559 mm x 1.6 mm dia.) FP-6: 6 in x 0.10 in (152 mm x 2.5 mm) FP-12: 12 in x 0.10 in (305 mm x 2.5 mm) FP-36: 36 in x 0.10 in (914.4 mm x 2.5 mm) FP-72: 72 in x 0.10 in (1829 mm x 2.5 mm)
IP Rating	IP68
Submersible	Yes
Operating Environment	-40 °C to +140 °C (-40 °F to +284 °F), 0 %RH to 100 %RH, 0.002 PSIA to 100 PSIA

HiTemp140X2-FP

Temperature
Temperature Sensor	HiTemp140X2-FP	Flexible RTD probe
	HiTemp140X2-FP-PT	Flexible RTD probe and bendable RTD probe
Probe Temperature Range	Flexible Probe	-60°C - 260°C (-76°F - 500°F)
	Bendable Probe	-200°C - 350°C (-328°F - 662°F)
Temperature Resolution	0.01°C (0.02°F)
Calibrated Accuracy	± 0.1°C / ± 0.18°F
General
Memory	32,767 Readings
Reading Rate	1 reading every 1 s up to 1 reading every 24 hrs
Memory Wrap-Around	Yes
Start Modes	Software programmable immediate start Delay start up to 18 months in advance
Stop Modes	Manual or Timed (specific date and time)
Trigger Settings	High and Low limits may be set. Once data meets or exceed sets limits, the device will record to memory. Bi-level start and stop triggers can also be programmed. Users can specify the number of readings to take after the device triggers. (Triggering on channel #1 only)
Readings in Trigger Settings Mode

• Autoclave verification
• Implement HACCP programs
• Food preparation & processing
• Environmental studies
• Well monitoring
• Washer disinfectors
• Pasteurization
