MC6 Multi-Cal Benchtop Calibrator

Modular sensor design allows user to select pressure measurement range for application flexibility

Buy now!

$7,144.13CAD

Have questions? We're here to help!

Call

QTY

Used in

Model MC6 Multi-Cal Benchtop Calibrator performs a wide variety of simple and complex pressure based measurement, test, and calibration operations. Modular sensor design allows user to select pressure measurement range for application flexibility. Calibrator can accommodate up to two interchangeable pressure modules (sold separately) in any combination of range or accuracy.

Simultaneously display two separate measurements on the two line, alphanumeric display. Readings can be displayed in a choice of twelve preprogrammed engineering units or any single user-defined unit. Calibrator features min/max recall, hi/lo alarm, percentage of full scale pressure readings, mA/voltage measurement, leak rate and pressure decay measurement, switch testing capabilities, including trip point and dead band, and velocity/volume flow rates.

Quickly document calibration procedures using the data logging feature which stores up to 384 sets of pressure and time/date stamped measurements. The automatic % error calculation simplifies transmitter calibration. Easily upload stored data to an IBM compatible computer via the RS232 two-way communications port. Calibrators and modules include certification to NIST traceability--ideal as a secondary standard for calibrating pressure equipment.

Multi-Cal Pressure Calibrator includes utility software, protection module, adjustment handle, AC adapter, and instruction manual.

Multi-Cal Pressure Modules are interchangeable and available in a wide selection of pressure ranges and accuracies (contact customer service for additional ranges). Benchtop calibrator accepts up to two pressure modules. Modules include NIST calibration certification.

Weight:	Calibrator: 3 lb (1.4 kg); Pressure Module: 0.5 lb (0.3 kg).
Housing Material:	ABS plastic.
Computer Requirements:	IBM compatible 386 or above and Windows® 3.1 or later with 2MB RAM and 2MB hard drive disk space, one serial port.
Baud Rate:	300, 1200, 2400, or 9600, selectable.
Dampening:	(Measurement averaging) programmable from 0 to 16 consecutive readings.
Temperature Effect Electrical Measurement:	±0.001% of span per °F over compensated range.
Temperature Error:	Maximum of ±0.004% of span per °F over compensated range for zero and span.
Temperature Compensation:	20 to 120°F (-7 to 49°C).
Overpressure:	Differential Pressure Modules: 50 psi positive direction, 15 psi negative direction, Gage Pressure Modules: 2x range (0/5 psi to 0/1000 psi).
Engineering Units:	In H2O, psi, in Hg, kPa, mbar, bar, cm H2O, mm Hg, ft SW, MPa, mm H2O, kg cm² and user-defined.
Memory Backup Requirements::	VL1220 or BR1225 Lithium Metal battery, installed functional, user replaceable.
Power Supply:	110 VAC/60 Hz adapter, 500 mA.
Electrical Connections:	Standard banana jacks.
Process Connection:	1/8" female NPT.
Storage Temperature:	-4 to 158°F (-20 to 70°C).
Ambient Operation Temperature:	32 to 120°F (0 to 49°C).
Display Update:	100 ms.
Display:	Alphanumeric LCD, 0.37" (9.5 mm) height per line, 2 lines, 16 characters/line.
Alarm Output:	SPST form C 110 VDC, 120 VDC (max.), 1 A (mas.), 30 W, 62.5 VA (resistive).
Output:	RS232 serial interface, 9-pin.
Repeatability:	Ranges ≤0/2 psi: ±0.05% of span, Ranges ≥0/5 psid: ±0.02% of span.
Sensitivity:	±0.002% of span with dampening 1 part in 50,000 (max.).
Accuracy:	Differential Pressure Modules: ±0.06% FS, Gage Pressure Modules: ±0.05% FS, Voltage Input: ±0.025% FS @ 1/10 VDC, ±0.10% FS @ 0/30 VDC, Current Input: ±0.03% FS @ 1/20 mA, ±0.05% FS @ 0/50 mA.
Service:	Clean, dry, nonconductive, noncorrosive gases.
