Dwyer

MDPC Mini Digital Pressure Controller

High measurement accuracy, high shock and vibration resistance, 6 user selectable pressure units

Starting At
$139.00 CAD
Normally ships in 3-4 Weeks

Configure   Request Quote

Can We Help You?

CALL US   EMAIL US   CHAT LIVE

Our product experts are here to help you find the right solution for your application!

The Series MDPC is a slim, gas pressure sensor that is small in size and light in weight. This pressure controller supports many installation methods and features high measurement accuracy. This small controller yields excellent stability, high shock and vibration resistance. The MDPC also provides good over-load capacity and heat resistance. It can be utilized in many industries such as: high-tech electronics, general processing, food packaging and automatic assembly. The MDPC features 6 user selectable pressure units and a large, LED 3-color display with selectable color options that allow for easy reading. Changing units is simple, and by using the included unit stickers, the pressure unit displayed becomes very clear. The fast parameter copy function makes copying parameters to other MDPC pressure controllers effortless. The key lock mode also prevents any unnecessary changes to the parameters, which can have an effect on the operation. Another characteristic of this multi-talented pressure controller is its ability to detect both positive and negative pressure. The MDPC is available in NPN, PNP, analog voltage or current output control modes.

• Energy saving mode
• 3-color display with selectable color options: green, red and orange
• Analog output function
• Parameter copy function
• Unit conversion function: in Hg, PSI, kPa, mm Hg, kg/cm2 and Bar
• 10 sets of user selectable output response times
• Key lock function
• Fast zero reset


Service Non-corrosive gas
Wetted Materials Brass with nickel plating
Housing Materials Polycarbonate, polybutylene terephthalate
Accuracy 3% of full range
Pressure Limits MDPC-1: 29 PSI (200 kPa);
MDPC-2: 217.6 PSI (1500 kPa)
Display 2-line LCD display, 4 digits for measured value and 3.5 digits for setup display
Power Requirements 12 VDC - 24 VDC, 10% no isolations
Power Consumption 40 mA max.; Current output type 60 mA max
Process Connections 1/8 in NPT, inner connection M5, for 1/8 in PT contact factory
Weight 1.3 oz (36.85 g)
Agency Approvals CE: MDPC-121, MDPC-122, UL
SWITCH SPECIFICATIONS
Switch Type NPN or PNP
Electrical Rating 100 mA @ 30 VDC
Response Time Programmable to 2 ms, 4 ms, 10 ms, 30 ms, 50 ms, 100 ms, 250 ms, 500 ms, 1000 ms or 5000 ms
Display Cycle Programmable to 100 ms, 250 ms, 500 ms or 1000 ms
TRANSMITTER SPECIFICATIONS
Output Signal 1 - 5 V: Minimum output load resistance 1000 Ω;
4 - 20 mA: Maximum output load resistance 400 Ω
Zero and Span Adjustments Menu scalable within the range

• High-tech electronics
• General processing
• Food packaging
• Automatic assembly
