The Model MN-1 Mini-Node™ Communication Signal Converter is a low-cost device that converts half-duplex RS-485 serial communications signals into a signal that can be read by any computer with a USB port. The integral USB connector and RJ-45 connector reduces setup time by eliminating extra wiring. The Model MN-1 is powered via the USB connection which eliminates the need for an external power source. The compact size is great for field installation, control panels, and lab testing.
• Converts half-duplex RS-485 via USB port
• Reduces set up time of process controllers
| Power Requirement | No external power required. |
| Power consumption | 0.4 W. |
| Isolated Voltage | 3000 VDC. |
| Input Impedance | 96 kΩ. |
| USB Connector | B-Type (Female). |
| RS-485 Connector | RJ-45. |
| Baud Rate | 75, 150, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, and 115200 bps. |
| Compatibility | Full compliance with USB V.2.0 specification. |
| Compliance | CE |
• Oven, boiler, or chiller control
• Hot plates/melt pots
• Packaging equipment
• Environmental chambers
• Medical equipment
• Food service equipment
| Dwyer MN-1 Mini-Node RS-485 to USB Converter - Data sheet 317.6 KB |
| Dwyer MN-1 Mini-Node RS-485 to USB Converter - Manual 293.1 KB |
