Buy now! $12,237.25CAD
Edgetech Instruments

OxyMaster 16TDP Oxygen & Dew Point Analyzer

Fast, accurate and economic measurement of oxygen and dew point at trace levels

Buy now!
$12,237.25CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
Oxy Master 16 TDP Oxygen Dew Point Analyzer 01011
Oxymaster2 6

The Edgetech Instruments Model OxyMaster 16TDP was made for fast, accurate and economic measurement of Oxygen and Dew Point at trace levels.  A simple menu-driven software, touch-pad and large LCD-display allow easy and fast start-up of the instrument.  The unit measures Humidity between -0.1 and 1000 ppm and Oxygen between 0 - 10000 ppm.


• Oxygen and humidity measurement in one unit
• Oxygen measurement range 0-10000 ppm
• Humidity measurement -0.1-1000 ppm
• 4-20mA outputs, RS232 and data logging included
• User selectable measurement range
• Oxygen sensor - a micro fuel cell,P2O5 trace moisture sensor
• Power 85-230Vac, 24Vdc
• Clear text graphic display

Measuring Range:0 - 10000 ppm O2
Free programmable
Lowest range 0-10 ppm
Humidity Range:0.1 – 1000 ppm Humidity
Free programmable
Calibration:With calibration gas
Accuracy:±2% FSD (T= const.)
±5% FSD
Over full temperature range(at 0 -10 ppm +/- 1ppm)
Resolution:0.1 ppm to 100 ppm
1 ppm from 100 to
10000 ppm
0.1ppm Humidity
Response Time:90 % of FSC at 25°C
0-10 ppm < 45 s
T90 of Step changes < 60 sec.
Operating Temperature:0 - 50°C
Pressure:0.1- 1 bar
Outputs:2 x 4 -20 mA/DC isol.
Display:Graphic
System Diagnostics:Self diagnosis with display
Power:85 - 230 VAC, 44/60 Hz
Oxygen Sensor:Micro-Fuel Cell,
Sensor Warranty:1 year under normal use and maintenance
Expected Sensor Life:Over 2 years
Size:232 x 202 x 163mm (W x H x D)
Weight:5 kg

• Air Separators

  • Thumbnail of document Data Sheet - OxyMaster 16TDP Oxygen & Dew Point Analyzer
    Download

    Data Sheet - OxyMaster 16TDP Oxygen & Dew Point Analyzer

    Download
