Precision Digital

PD6870 ProtEX FarVu Explosion-Proof Loop-Powered Meter

Large 1" display digits, field mountable enclosure, approved for hazardous areas

Starting at
$703.50CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
PD6870 Prot EX Far Vu Explosion Proof Loop Powered Meter 00742
The ProtEX-FarVu is a rugged explosion-proof, loop-powered meter with 1" display digits available in aluminum or stainless steel enclosures. It is ideal for demanding applications in hazardous areas or in the harshest environmental conditions. The PD6870 is housed in an IP68, aluminum enclosure and is FM Approved and CSA Certified as Explosion-Proof, Dust-Ignition Proof, and Flame-Proof, and ATEX & IECEx Certified as Flame-Proof. The PD6870-SS is housed in a 316 stainless steel enclosure and is CSA Certified as Explosion-Proof, Dust-Ignition Proof, and Flame-Proof.

The ProtEX-FarVu meters will operate down to -40°C and the PD6870-SS stainless steel models can be installed in areas where the temperature gets as cold as -55°C, however, the display will cease functioning. The meter derives all of its power from the 4-20 mA loop with a small 1 volt drop for easy installation in almost any system.

The meter is programmed using four easy to access front-mounted potentiometers with no complex or difficult to read programming menus necessary for setup.

The numeric display will read from -1000 to 1999 over a 2000 count user adjustable scaling span. The backlight feature lets you see the display under any lighting condition and is powered from the 4-20 mA loop with no additional power supply required. The backlight can be enabled or disabled via alternative wiring of terminal block. The enclosure is provided with two conduit openings and the cast-in mounting flanges on the enclosure make it convenient for pipe or wall mounting.



• Fully-Approved Explosion-Proof Loop-Powered Process Meter
• 4-20 mA Input
• 1 Volt Drop (4 Volt Drop with Backlight)
• 1.0" (25.4 mm) 3½ Digits LCD Display; -1000 to 1999
• Display Mountable at 0°, 90°, 180°, & 270°
• HART® Protocol Transparent
• Loop-Powered Backlight Option
• Operating Temperature Range: -40 to 75°C (-40 to 167°F)
• Zero & Span Potentiometer Adjustments for Easy Field Scaling
• Conformal Coated PCBs for Dust and Humidity Protection
• FM Approved as Explosion-Proof / Dust-Ignition Proof / Flame-Proof
• CSA Certified as Explosion-Proof / Dust-Ignition Proof / Flame-Proof
• ATEX and IECEx Certified as Flame-Proof
• Wide Viewing Angle
• Flanges for Wall or Pipe Mounting
• Explosion-Proof, IP68, NEMA 4X Die-Cast Aluminum Enclosure
• Two ¾" NPT Threaded Conduit Openings (One Plug Installed)
• 2" U-Bolt Kits Available
• Stainless Steel Tag Available
• 3-Year Warranty
RecalibrationRecommended at least every 12 months.
Display3½ digit LCD, 1" (25.4 mm); -1,999 to 1,999
Display Update Rate2.5 Updates/Second
Display OrientationDisplay may be mounted at 90° increments up to 270° from default orientation
Over RangeDisplay reads 1 on the left most digit
Programming MethodFour front mounted trim potentiometers accessed when the cover is removed.
Normal Mode Rejection60 dB rejection ratio
Operating Temperature Range-40 to 75°C
Storage Temperature Range-40 to 75°C
Relative Humidity0 to 90% non-condensing
ConnectionsScrew terminals accept 12 to 22 AWG wire
EnclosureExplosion-proof die cast aluminum with glass window, 0.30% max copper content, corrosion resistant epoxy coating, color: blue. NEMA 4X, IP68. Two ¾" NPT threaded conduit openings. One ¾" NPT nickel plated brass conduit plug with 10 mm hex key fitting installed.
MountingMay be mounted directly to conduit. Two slotted flanges for wall mounting or NPS 1½" to 2½" or DN 40 to 65 mm pipe mounting.
Overall Dimensions (W x H x D)5.65" x 5.25" x 4.86" (144 mm x 133 mm x 124 mm)
Weight5.00 lbs (80 oz, 2.27 kg)
Warranty3 years parts and labor
  • Thumbnail of document Data Sheet - PD6870 ProtEX FarVu Explosion-Proof Loop-Powered Meter
    Download

    Data Sheet - PD6870 ProtEX FarVu Explosion-Proof Loop-Powered Meter

    Download
  • Thumbnail of document Manual - PD6870 ProtEX FarVu Explosion-Proof Loop-Powered Meter
    Download

    Manual - PD6870 ProtEX FarVu Explosion-Proof Loop-Powered Meter

    Download
