Amprobe

RTD-10 Dual Input Digital RTD Thermometer

Provides higher accuracy while maintaining long-term stability for superior repeatability of measurements


$164.00 CAD
Normally ships in 1-2 Weeks


  Request Quote

Can We Help You?

CALL US   EMAIL US   CHAT LIVE

Our product experts are here to help you find the right solution for your application!

The RTD-10 Dual Input Digital RTD Thermometer is preferred for industrial process applications. It typically provides higher accuracy then thermocouples and maintains stability for many years.

Resistive thermal devices (RTDs) are becoming the preferred temperature sensors for precision industrial applications. Instead of generating voltage, RTDs generate electrical resistance, which varies linearly with temperature. Amprobe RTD thermometers maintain long-term stability for superior repeatability of measurements, when compared to thermocouples.

The RTD-10 comes with a USB wireless module, four (4) 1.5 V AAA batteries (installed), and a user's manual.





• RTD dual input function
• Pt 3916/Pt 3926/Pt 385 RTD standard
• °C/°F user-selectable
• Warning beeper with hi/lo setting
• Resolution 0.1°C to 0.2°F
• Included accessories USB wireless module, user's manual, four (4) 1.5 V AAA batteries



RTD-10

Wireless Transmission

-

Temperature

RTD: Pt 385 (100 Ω), Pt 3916/Pt 3926 (100 Ω)
Range: Pt385 (100 Ω): -328°F - 1472°F (-200°C - 800°C)
Pt3916 / Pt3926 (100 Ω): -328°F - 1166°F (-200°C - 630°C)

Accuracy

± (0.05% RDG + 0.4°F) on °F scale
± (0.05% RDG + 0.2°C) on °C scale

Number of Parameters on the Display

3

Display

4½ digit liquid crystal display (LCD) with maximum reading of 19999

Polarity

Automatic, positive implied, negative polarity indication

Battery

Four (4) 1.5 V AAA size

Temperature Scale

°C and °F, user-selectable


For complete specifications please download the product datasheet under the “Resources" tab.
