Rain101A Rainfall Data Logging System

Complete system to accurately measure & record rainfall over long periods of time using a tipping-bucket rain gauge & data logger

Buy now!
$898.50CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
Rain101 A Rainfall Data Logging System 01841
Rain101 A 2
Rain101 A 3
Rain101 A 4

The Rain101A is a complete system to accurately measure and record rainfall over long periods of time. It comes complete with an Event101A data logger, weatherproof enclosure, tipping bucket rain gauge, 50 ft of cable and the IFC200 interface cable and software package.

It can record up to 6 in of rainfall every hour and 131 in of rainfall total. The Rain101A only records to memory when rainfall is present, maximizing the amount of time the system can record. Using the logger’s built-in Engineering Units, the data can be offloaded and displayed in user-specified units (eg. inches, centimeters). The software can “totalize” the rain bucket tips, allowing easy viewing of the accumulated rainfall over the time period of interest.

The Rain101A features a 10 year battery life, 4 Hz reading rate, a multiple start/stop function, ultra-high speed download capability, 406,323 reading storage capacity, optional memory wrap, battery life indicator, optional password protection and more.

• Water resistant housing for logger
• High-precision tipping bucket
• Records 0 ft - 338 ft of rainfall
• Self-emptying
• 10 year battery life
• Multiple start/stop function
• Rugged construction
• Ultra high speed download
• Battery life indicator
• Optional password protection
• Field upgradeable

Rainfall Accuracy±4 % over range of 1 in to 6 in per hour
Orfice8 in dia. (204 mm dia.)
Reed Switch Contact Rating3 W, 28 VAC
Rainfall per Bucket Tip(3) 1/4 in dia. holes on 9.5 in dia. circle
Rainfall Tripod/Mask KitContact factory for availability
Memory406,323 samples, 338 ft of rainfall
Reading Rate4 Hz to 1 every 24 hours
Baud Rate115,200
Push-Button StartYes
Battery Life10 years Typical
MaterialFunnel: anodized aluminum; base, body and bracket
Tipping Bucket: PVC
Data Logger: ABS Plastic
DimensionsRain Gauge: 12.0 in x 8.4 in dia. (305 mm x 214 mm dia.)
Weatherproof Enclosure: 3.5 in x 2.9 in x 1.1 in (87 mm x 73 mm x 27 mm)
Operating Environment-20 °C to +80 °C (-4 °F to +176 °F), 0 %RH to 100 %RH
Required Interface PackageIFC200

Rainfall

Rainfall Accuracy

± 4% over range of 1 in - 6 in per hour

Orifice

8 in dia. (204 mm dia.)

Reed Switch Contact Rating

3 W, 28 VAC

Rainfall Per Bucket Tip

0.01 in (0.254 mm)

General

Memory

406,323 samples, 338 ft of rainfall

Reading Rate**

4 Hz to 1 every 24 hrs

Mounting

3 x 1/4 in dia. Holes on 9.5 in dia. circle

Baud Rate

115,200

Wrap Around

Yes

Start Modes

Immediate start

Delay start up to 18 months

Multiple pushbutton start/stop

Multiple Start/Stop Mode

Start and stop the device multiple times without having to download data or communicate with a PC

Multiple Start/Stop Mode Activation

To start the device:

<

• Seasonal rainfall data logging
• Irrigation studies
• Precipitation studies
