Dwyer

SG1 1.5 in Industrial Pressure Gage

Perfect for applications where resistance to corrosion is necessary as the stainless steel case and ring offer protection from harsh processes

Starting At
$26.00 CAD
Normally ships in 2-3 Weeks

Configure   Request Quote

Can We Help You?

CALL US   EMAIL US   CHAT LIVE

Our product experts are here to help you find the right solution for your application!

The Series SG1 Gages are perfect for applications where resistance to corrosion is necessary. The stainless steel case and ring offer excellent protection from harsh processes. The SG1 gages are an economical choice where ambient corrosion and vibration are a concern. Gages are suitable for all fluids that are compatible with brass and bronze, and are available with bottom or back connections.

• Stainless steel housing to resist ambient corrosion for longer service life in harsh environments
• Good accuracy gage for value-sensitive applications requiring more precise measurement and where vibration is a concern
• Back or bottom mounting and compact size provides for mounting with dimensional limitations


Service Compatible gases and liquids
Wetted Materials Brass connector, bronze tube
Housing 304 SS
Lens Polycarbonate
Accuracy 2.5% FS
Pressure Limit FS range
Temperature Limits 4F - 140F (-20C - 60C)
Size 1.5 in (40 mm)
Process Connections 1/8 in NPT
Weight 2.2 oz (63 g) bottom, 2.3 oz (65 g) back

• Vacuums in pneumatic conveying lines
• Positive pressure in compressed air headers
• Corrosive ambient environments
