Dwyer

SGY 2.5 in Industrial Pressure Gage

Dual PSI and Bar (x100 kPa) scales with 1.5% full-scale accuracy, stainless steel housing and wetted parts

Starting At
$26.00 CAD
Normally ships in 3-4 Weeks

Configure   Request Quote

Can We Help You?

CALL US   EMAIL US   CHAT LIVE

Our product experts are here to help you find the right solution for your application!

The Series SGY Gages have dual PSI and Bar (x100 kPa) scales with ± 1.5% full-scale accuracy. The Series SGY gages are designed with 304 SS housings and brass wetted parts for excellent chemical compatibility. These gages cover a wide variety of ranges from full vacuum to 1,000 PSI and are available in both bottom or back connections. Series SGY gages employ an easy-open breather plug on top, which allows liquid filled units to breathe, relieving any built up internal pressures. Plug easily pops open and does not need to be entirely removed or cut like a typical gages' rubber plug grommet.

• Stainless steel housing and wetted parts to resist ambient corrosion for longer service life in harsh environments
• Higher accuracy gage for value-sensitive applications requiring more precise measurement and where vibration is a concern
• Optional sliding pointer clearly mark to make visible critical ranges and high and low points
• Liquid fillable gage with easy open breather plug provides smoother damped movement of pointer
• Back or bottom mounting and compact size provides for mounting with dimensional limitations


Service Compatible gases and liquids
Wetted Materials Brass connection, bronze tube
Housing 304 SS
Lens Polycarbonate
Accuracy 1.5% FS
Pressure Limit FS range
Temperature Limits -4F - 140F (-20C - 60C)
Size 2.5 in (63 mm)
Process Connections 1/4 in male NPT
Weight 4.9 oz (139 g) bottom, 5.8 oz (164 g) back.
Add 2.8 oz (78 g) for fill

• Vacuums in pneumatic conveying lines
• Positive pressure in compressed air headers
• Corrosive ambient environments
