The Series PMT2 Particulate Transmitter is designed to measure particulate emission levels from dust collector discharge. Using DC coupled electrostatic induction sensing technology, the transmitter monitors a pA current that is generated as particulate passes near the probe; a 4 to 20 mA signal will vary based on the particulate level. The PMT2 offers 6 sensitivity ranges allowing the user to choose the range that will best fit the application. The range and test selector switch can also be set to output a 4 mA or 20 mA signal to assist with set up or trouble shooting. Averaging time setting can be used to dampen the signal if desired.
• Simple 2-wire installation for PLC and control panels
• Non-stick PTFE coated probe to prevent false readings from moist and conductive dusts, condensate, and dust buildup
• Remote zero calibration helps to decrease maintenance time
| Service | Air and compatible gases, any type of particulate conductive or nonconductive. |
| Wetted Materials | 316L SS, silicone, and PTFE. |
| Enclosure | Powder coated aluminum. |
| Accuracy | ±5% of reading. |
| Particulate Size | 0.3 microns and higher. |
| Detection Range | 5 to 5000 pA (6 selectable range options). |
| Temperature Limits | Ambient: -40 to 145°F (-40 to 63°C); Process: -40 to 248°F (-40 to 120°C). |
| Pressure Limit | 30 psi (2 bar). |
| Output Signal | 4 to 20 mA. |
| Power Requirements | 12 to 28 VDC. |
| Electrical Connection | Two 1/2" female NPT conduit openings. |
| Terminal Block | Removable (16 to 20 AWG wire). |
| Process Connection | See model chart on catalog page. |
| Probe Lengths | See model chart on catalog page. |
| Enclosure Rating | UL Type 4 (IP66), ATEX/IECEx IP65. |
| Mounting Orientation | Any. |
| Averaging Time | 1 to 360 s (10 selectable options). |
| Weight | Varies with length of probe and type of mount. |
| Compliance | CE, cULus; ATEX Compliant: 2813 II 1 G Ex ia IIB T4 GA (-40°C ≤ Tamb ≤ 63°C) (-40°C ≤ T Process ≤ 120°C) / II 1 D Ex ia IIIC T120°C Da (-40°C ≤ Tamb ≤ 63°C) (-40°C ≤ T Process ≤ 120°C). Type Certificate No.: DEMKO 16ATEX1768 X. ATEX Standards: EN 60079-0:2012/A11:2013; EN 60079-11:2012. IECEx Certified: Ex ia IIB T4 Ga (-40°C ≤ Tamb ≤ 63°C) (-40°C ≤ T Process ≤ 120°C) / Ex ia IIIC T120°C Da (-40°C ≤ Tamb ≤ 63°C) (-40°C ≤ T Process ≤ 120°C). Certificate of Conformity: IECEx UL 16.013X. IECEx Standards: IEC 60079-0: 2011; IEC 60079-11: 2011. UL Listed Intrinsically Safe for Class I, Groups C and D; Class II, Groups E, F and G; Class III; Class I Zone 0 AEx ia IIB T4 Ga; Class I Zone 0 Ex ia IIB T4 Ga. |
• Emissions monitoring
• Broken bag detection in dust collectors
• Filter leak or wear detection
• Bin vent monitoring
