Standard Industrial Sight Flow Indicator

View-through, two opposing windows that are gasketed & mounted w/ bolted retainers; flange connection or threaded mount

Have questions? We're here to help!

Call

Used in

Standard Industrial Sight Flow Indicator 05326

Extensive engineering and design have resulted in the highest industry standard for visual flow indicator technology. Uncompromising levels of quality, safety and technological excellence are standard features in the complete line of L.J. Star Incorporated Standard Models of visual flow indicators. They are available in flange connection or threaded mount.

All standard flanged and threaded models in the L.J. Star Incorporated line of visual flow indicators carry full ANSI rating and are available in several application specific configurations. ANSI designed for 150# or 300# service, threaded units are available in sizes from 1/2 in to 2 in while flanged units are available in sizes from 1/2 in to 8 in.

This L.J. Star product carries Canadian Registration Number (CRN) registration.

• Mounting: Flange or FNPT connection
• 150 or 300 full PSI ANSI classes
• Up to 500°F
• Full ANSI rated
• Indicator options: Rotor, flapper, drip-tube or plain
• Sizes: 1/2 in - 2 in (Threaded) or 1/2 in - 8 in (Flange)

150 PSI

Standard Threaded Model

Pipe Size	Dimensions			Approximate Weight (lbs)
Pipe Size	A	B	C	Approximate Weight (lbs)
1/2 in	3-3/4 in	1-1/4 in	3-7/8 in	6
3/4 in	3-3/4 in	1-1/4 in	3-7/8 in	6
1 in	4-1/4 in	1-1/4 in	4-1/8 in	11
1-1/2 in	5-1/2 in	1-3/4 in	5-3/8 in	12
2 in	6-1/4 in	2 in	6-1/8 in	17

Standard Flanged Model

Pipe Size	Dimensions			Approximate Weight (lbs)
Pipe Size	A	B	C	Approximate Weight (lbs)
1/2 in	4-5/8 in	1-1/4 in	4-3/16 in	6
3/4 in	4-5/8 in	1-1/4 in	4-3/16 in	6
1 in	5-5/8 in	1-1/4 in	4-1/8 in	11
1-1/2 in	6-1/2 in	1-3/4 in	5-3/8 in	17
2 in	7-7/8 in	2 in	6-1/8 in	27
3 in	9-3/8 in	3-3/16 in	7-3/4 in	56
4 in	11 in	4-1/8 in	10-5/8 in	75
6 in	14-1/4 in	6
