TS Digital Temperature Switch

3-digit display, heating and cooling control, with 8 or 16 A relay

Starting at

$218.63CAD

Have questions? We're here to help!

Call

Configure

Used in

The TS Digital Temperature Switch is designed to regulate many heating and cooling applications. Easy programming via the tactile front keypad enables quick setup of the 12 parameters for simple, reliable operation. The user can define set point, heating/cooling regulation, hysteresis, cycle time, ambient probe adjustment and defrosting time. The unit features error or alarm messaging and password protection. View probe temperature on the bright red, 3-digit LED display. Select between temperature display in °F or °C, and 110 VAC, 230 VAC, or 12 VDC power supplies. The Series TS includes a thermistor with 5 ft (1.5 m) cable, fitting clips for panel mounting, gasket, rear terminal cover, and instruction manual.

• Define set point, heating/cooling regulation, hysteresis, cycle time, ambient probe adjustment and defrosting time.
• Features error or alarm messaging and password protection.
• Probe temperature displayed on the bright red, 3-digit LED display.
• Temperature display in °F or °C, and 110 VAC, 230 VAC, or 12 VDC power supplies.
• Includes a thermistor with 5 ft (1.5 m) cable, fitting clips for panel mounting, gasket, rear terminal cover, and instruction manual

Probe Range	-58°F - 302°F (-50°C - 150°C)
Input	1.5 in (4 cm) thermistor (1000 Ω @ 25°C) with 5 ft (1.5 m) cable
Output	16 A SPDT relay @ 250 VAC resistive
Horsepower Rating (HP)	1 HP for 16 A
Control Type	ON/OFF
Power Requirements	110 VAC, 230 VAC or 12 VAC/VDC (depending on model)
Accuracy	± 1°C
Display	3-digit, red, 1/2 in digits
Resolution	1°
Memory Backup	Nonvolatile memory
Temperature Limits	Ambient: 32°F - 158°F (0°C - 70°C)
Storage Temperature	-4°F - 176°F (-20°C - 80°C)
Weight	2.3 oz (65 g)
Front Panel Rating	IP64
Agency Approvals	CE, ULc, UL

• Industrial chillers
• Environmental chambers
• Walk-ins and freezers
• Heat sealers
• Sterilizers
• Beer and wine chillers
• Mug frosters
• Coolers
• Display cases and cabinets
• Warmers
• Meat and produce storage
• Floral preservation
• Refrigerated transportation
• Laboratories
• Food service equipment
• Ovens and dryers
• Tobacco preservation
• Hot melt glue stichers for case erectors
• Cool rooms
• Burn-in rooms and chambers
• Cold water citrus packing
