Starting at $4,800.00CAD

ULT90 Ultra Low Temperature Data Logging System

Name: ULT90 Ultra Low Temperature Data Logging System
Brand: Madgetech
SKU: placeholder-ult90-ultra-low-temperature-data-logging-system
Price: 4800.00 CAD
Availability: InStock

Can measure & log data as low as -86°C, can be placed in small & large freezers of varying configurations, hardware & software password protection

Starting at

$4,800.00CAD

Have questions? We're here to help!

Call

Configure

Used in

ULT90 Ultra Low Temperature Data Logging System 01843

The ULT90 Includes:
(9) (15) CryoTemps: Ultra-Low Temperature Data Logger
(1) IFC300: Cable Interface
(1) MadgeTech 4 Secure Software and IQ/OQ/PQ Validation Protocols

The ULT90 is an ultra-low temperature freezer validation system, measuring temperatures as low as -86 °C (-122.80 °F). This system provides a complete temperature mapping and validation solution to ensure proper storage and testing conditions.

The CryoTemp provides 32,767 date and time stamped temperature readings with an accuracy of ±1.0 °C (1.8 °F). Equipped with high/low alarm limits and high/low warning limits the user will be alerted when the temperature nears unacceptable levels.

The MadgeTech 4 Secure Software aids users in compliance with 21 CFR Part 11 requirements. The software ensures electronic signatures, access codes, secure data file and audit trails meet standards.

•ISO17025 Accredited Calibration certificates
• FDA 21 CFR part 11 compliant
• IQ/OQ/PQ validation protocols
• Available with 9 or 15 Splash-proof cryo-temp data logger
• -86°C - 35°C (-122 °F to +95 °F) temperature range
• One year battery life at -80°C (-112 °F)
• User-programmable temperature alarms with LED’s (OK, Warn, and Alarm)
• Hardware and software password protection
• Simultaneous starts, memory wrap
• User-programmable start times, sample intervals, logger descriptions, unique ID’s

General
Memory	32,767 readings
Reading Rate	1 reading every 5 seconds up to 1 reading every 30 minutes
Single/Multi-Use	Multi-use
Battery Life	2 years typical at 25 °C, 1 min. reading intervals 1 year typical at -80 °C, 1 min. reading intervals
Material	ABS plastic
Dimensions	3.3 in x 2.1 in x 0.4 in, (83 mm x 54 mm x 11 mm)
Operating Environment	-86 °C to +35 °C (-122.8 °F to +95 °F), 0 %RH to 100 %RH
Required Interface Package	IFC300
Approvals	CE
Temperature
Temperature Sensor	Thermistor
Temperature Range	-86 °C to +35 °C (-122.8 °F to +95 °F)
Temperature Resolution	0.1 °C (0.18 °F)
Temperature Calibrated Accuracy	±1.0 °C (1.8 °F)

• Ultralow freezer validation
• Ultralow freezer mapping
• Ultralow freezer stabilization studies
• Temperature surveys
    - Reveal stratification of air
    - Reveal hot spots
    - Reveal anomalies in chilling systems
