Dwyer

V6 Flotect Mini-Size Flow Switches

Weather proof & explosion proof, easy intallation, features a free swinging vane

Starting At
$259.00 CAD
Normally ships in 3-4 Weeks

Configure   Request Quote

Can We Help You?

CALL US   EMAIL US   CHAT LIVE

Our product experts are here to help you find the right solution for your application!

The Series V6 Flotect® Flow Switches is surprisingly compact, and specifically engineered to monitor liquid, gas, or air flows. Time tested in thousands of pipeline installations and processing plants around the world, this Series is Weatherproof, designed to meet NEMA 4 and Explosion-proof (listing included in specifications). Tees are available for installation in pipelines from 1/2 in - 2 in (12.70 mm - 50.80 mm). With bushings added the unit is easily adapted to 1/4 in and 3/8 in (6.35 mm and 9.53 mm) piping.

• Leak proof body machined from bar stock
• Choice of models in a tee with calibrated vane or field adjustable trimmable vane
• Electrical assembly can be easily replaced without removing the unit from the installation so that the process does not have to be shut down
• High pressure rating of 1000 PSIG (69 Bar) with brass body and 2000 PSIG (138 Bar) on the 316 SS body
• Low flow model offers field adjustable set point
• Easy installation with simply pipe insert via the tee & simple electrical switch connections
• Unique magnetically actuated switching design gives superior performance
• Features a free-swinging vane which attracts a magnet within the solid metal switch body, actuating a snap switch by means of a simple lever arm with no bellows, springs, or seals to fail


Service Gases or liquids compatible with wetted materials
Wetted Materials Standard V6 Models:
Vane: 301 SS;
Lower Body: brass or 303 SS;
Magnet: ceramic;
Other: 301, 302 SS;
Tee: brass, iron, forged steel, or 304 SS.
V6 Low Flow Models:
Lower body: brass or 303 SS;
Tee: brass or 304 SS;
Magnet: ceramic;
O-ring: Buna-N standard, Fluoroelastomer optional;
Other: 301, 302 SS
Temperature Limits -4F - 220F (-20C - 105C). See Data Sheet for details
Pressure Limit Brass lower body with no tee models 1000 PSIG (69 Bar), 303 SS lower body with no tee models 2000 PSIG (138 Bar). Brass tee models 250 PSI (17.2 Bar), iron tee models 1000 PSI (69 Bar), forged and stainless steel tee models 2000 PSI (138 Bar), low flow models 1450 PSI (100 Bar)
Enclosure Rating Weatherproof and Explosion-proof. Listed with UL and CSA for Class I, Groups A, B, C and D; Class II, Groups E, F, and G. (Group A on stainless steel body models only). ATEX 0344 II 2 G Ex d IIC T6 Gb Process Temp≤75C Alternate Temperature Class T5 Process Temp≤90C, 115C (T4) Process Temp ≤105C consult factory. IECEx Certificate of Conformity: IECEx DEK 11.0039; IECEx Standards: IEC 60079-0: 2007; IEC 60079-1: 2007; Korean Certified (KC) for: Ex d IIC T6 Gb Process Temp =75C; KTL Certificate Number: 2012-2454-75
Switch Type SPDT snap switch standard, DPDT snap switch optional
Electrical Rating UL models: 5 A @125/250 VAC. CSA, ATEX and IECEx models: 5 A @ 125/250 VAC (V~); 5 A res., 3 A ind. @ 30 VDC (V ). MV option: .1 A @ 125 VAC (V~). MT option: 5 A @125/250 VAC (V~). [MT option not UL, CSA, ATEX or IECEx]
Electrical Connections UL models: 18 AWG, 18 in (457.20 mm) long. ATEX/CSA / IECEx models: terminal block
Upper Body Brass or 303 stainless steel
Conduit Connections 3/4 in (19.05 mm) male NPT standard, 3/4 in (19.05 mm) female NPT or M25 with BSPT option on junction box models
Process Connection 1/2 in (12.70 mm) male NPT or 1/2 in (12.70 mm) male BSPT on models without a tee
Mounting Orientation Switch can be installed in any position but the actuation/deactuation flow rates in the charts are based on horizontal pipe runs and are nominal values
Set Point Adjustment Standard V6 models none. Without tee models vane is trimmable. Low flow models are field adjustable in the range shown. See set point charts on Catalog page
Weight 2 lb - 6 lb (0.9 kg - 2.7 kg) depending on construction
Options Not Shown Custom calibration, bushings, PVC tee, reinforced vane, DPDT relays
Agency Approvals ATEX, CE, CSA, IECEx, KTL, UL

• Protects pumps, motors and other equipment against low or no flow
• Controls sequential operation of pumps
• Automatically starts auxiliary pumps and engines
• Stops liquid cooled engines, machines and processing when coolant flow is interrupted
• Shuts down burner when air flow through heating coil fails
• Controls dampers according to flow
• Signals alarm when emergency shower or eyewash station in use
