VP3 100 MM Vane Thermo-Anemometer Probe

Measures air velocity, air flow, humidity, and temperature when combined with the Model UHH6 Universal Handheld

Buy now!

$760.73CAD

Have questions? We're here to help!

Call

QTY

Used in

VP3 100 MM Vane Thermo Anemometer Probe 08785

VP3 100 MM Vane Thermo Anemometer Probe 3d5a8

VP3 100 MM Vane Thermo Anemometer Probe 43270

VP3 100 MM Vane Thermo Anemometer Probe 57842

VP3 100 MM Vane Thermo Anemometer Probe c05f7

The Model VP3 Wireless 100 mm Vane Thermo-Anemometer Probe measures air velocity, air flow, humidity, and temperature when combined with the Model UHH6 Universal Handheld. By having a larger diameter, the rotating vane is able to measure velocities down to 50 fpm or 0.25 m/s. An arrow is molded into the vane housing to depict the flow direction.

These probes use a Bluetooth Low Energy (BLE) signal for effortless connection and low power consumption. Wireless probes can take measurements up to 50 feet away from the UHH6 or compatible handheld. A bicolor LED flashes on the handle of the probe to indicate communication status with the handheld device. The battery is rechargeable via the mini-USB connector on the bottom of the probe.

• Allows for one handed operation for ladder use safety

• Stable 50 ft (15 m) wireless range

Service	Dry, clean air.
Temperature Limits	Process: -20 to 212°F (-29 to 100°C); Ambient: 5 to 125°F (-15 to 51°C).
Range	Air velocity: 40 to 5000 FPM (0.2 to 25 m/s); Volumetric air: 999,999 in selected flow units; Temperature: -20 to 212°F (-29 to 100°C); Relative humidity: 0 to 100% RH.
Accuracy	Air velocity: 100 to 3500 fpm: ±5% of reading ±7 fpm (0.5 to 20 m/s: ±5% of reading ±0.04 m/s); Temperature: ±0.54°F @ 77°F (±0.3°C @ 25°C); Relative humidity: ±2% @ 77°F (25°C) (10 to 90% RH); ±4% (0 to 10% RH and 90 to 100% non-condensing).
Resolution	1 FPM (0.001 m/s).
Response Time	Air velocity and air volume: 1 s; Temperature and relative humidity: 1.5 s.
Probe Length	8" (203 mm) insertion.
Battery Charging Limits	32 to 113°F (0 to 45°C).
Power Requirements	3.7 V YT562447 Lithium ion battery.
Maximum Wireless Distance	50' (15 m).
Handle Enclosure	Thermoplastic elastomer over polycarbonate.
Supplies With	Wrist Strap
Weight	13.6 oz (385 g).
Agency Approvals	CE (not while charging), FCC compliant.
