VT04/VT04A Visual IR Thermometers

Compact & intuitive, these visual infrared thermometers blend a visual image w/ a heat map overlay to help quickly identify the location of issues

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!

Call

VT04 VT04 A Visual IR Thermometers 01151

With the VT04 Visual IR Thermometers, see issues in context by blending the infrared heat map with the visual image. Get the detail you need by choosing one of five on screen blending modes. Quickly identify the location of the issue - NEAR or FAR mode automatically aligns the visual and thermal lenses – even from as close as 15 cm (6 in). Capture accurate temperature readings without taking your eyes off the screen. The center measurement box shows the exact area of temperature measurement. Fill the center box with your target and rest assured you're not measuring the background.

Identify intermittent problems by monitoring equipment over time or get alerts when a temperature is outside the expected range with temperature alarms and automated monitoring features. Instantly identify the hottest and coldest spots within the field of view with hot and cold markers. VT04 images can be taken in either .bmp or .is2 format.

Two VT04 combo kits are available to provide complete solutions to your electrical and maintenance issues. The VT04 maintenance combo kit includes the VT04 Visual IR Thermometer and the 1507 Insulation Resistance Tester.

• Compact and intuitive visual IR thermometer that blends a visual image with infrared heat map overlay
• Features NEAR and FAR mode that automatically aligns visual and thermal lenses to correctly locate issues
• Includes a center measurement box showing the exact area of temperature measurement on the screen
• Features PyroBlend® Plus optics to provide excellent field of view for tight spaces and sharp images
• Provides temperature alarms and automated monitoring to identify intermittent problems over time or get alerts of a temperature outside the expected range
• Presents hot and cold markers to instantly identify the hottest and coldest spots within the field of view
• Saves results in .bmp format when you only want an image, or in .is2 format that you can use with Fluke SmartView® software
• Features a pocket-size design that easily fits in your tool bag or pocket
• Offers a highly intuitive interface so you can get to work immediately
• Includes a soft case, micro SD card and adapter, and 4 AA batteries

Specifications
Built-In Visual Camera	Yes, get the context of visible light details in your images
Infrared Heat Map and Visual Image Blending	Yes, five blending modes on camera and continuous blending in SmartView® software
Image Optics System	PyroBlend Plus optic (4 x sharper image than VT02)
Field of View	28 in x 28 in; the tight field of view lets you see more detail in your target
Alignment Options	NEAR	< 23 cm (9 in) from target
	FAR	> 23 cm (9 in) from target
Temperature Measurement Range	-10°C - 250°C (14°F - 482°F)
Focus system	Focus free
High/Low Temperature Alarms	Yes, high and low temperature alarms flash whenever the temperature threshold is exceeded, alerting you when a temperature is outside the expected range
Time-Lapse Image Capture	Yes, automatically capture images at set intervals to see how temperature patterns change over time
Auto-Monitor Alarm	Yes, gain insight into intermittent problems by automatically capturing images when your selected temperature threshold is exceeded
