Starting at $482.55CAD

160F Straight Stainless Steel Pitot Tubes

Name: 160F Straight Stainless Steel Pitot Tubes
SKU: placeholder-160f-straight-stainless-steel-pitot-tubes
Price: 482.55 CAD
Availability: InStock

Constructed from corrosion resistant stainless steel with permanently etched insertion depth graduations for a lifetime of service

Starting at

$482.55CAD

Have questions? We're here to help!

Call

Configure

Used in

160 F Straight Stainless Steel Pitot Tubes 07342

160 F Straight Stainless Steel Pitot Tubes 6b805

160 F Straight Stainless Steel Pitot Tubes b52d7

The Series 160F Straight Stainless Steel Pitot Tube is constructed from corrosion resistant stainless steel with permanently etched insertion depth graduations for a lifetime of service. The static pressure port is parallel to the sensing tube to allow quick, easy alignment of the tube with air flow. The straight design allows for easy insertion into ducts through grills and pressure taps, as well as aids in positioning in hard to reach locations where a hook style Pitot tube may not allow access.

• Straight design allows for easy insertion into ducts

• Permanent stamped insertion depth graduations facilitate accurate positioning

• Alignment indicator helps keep tip parallel to flow

Agency Approvals:	Meets the technical requirements of EU Directive 2011/65/EU (RoHS II).
Weight:	4.3 oz (122 g).
Process Connections:	1/4" OD.
Max. Temperature:	1500°F (815°C).
K-Factor:	0.81.
Accuracy:	±2% FS, 0 to 9000 FPM (45 M/s).
Material:	304 SS.

• Monitor or control air velocity or air flow when combined with differential pressure gage, switch, or transmitter where hook style Pitot tubes don’t allow access
