Starting at $4,069.79CAD

1623-2 / 1623-2-KIT GEO Earth Ground Tester

Name: 1623-2 / 1623-2-KIT GEO Earth Ground Tester
SKU: placeholder-1623-2-1623-2-kit-geo-earth-ground-tester
Price: 4069.79 CAD
Availability: InStock

Unique earth ground tester that can performs all four types of earth ground measurement

Starting at

$4,069.79CAD

Have questions? We're here to help!

Call

Configure

Used in

1623 2 1623 2 KIT GEO Earth Ground Tester 01096

The Fluke 1623-2 GEO Earth Ground Tester offers data storage and download capabilities via USB port. World class accessories will simplify and speed up testing time. Model 1623-2 offers 3- and 4-pole Fall-of-Potential, earth resistance loop testing, and 4-pole Soil Resistivity testing. Also offered is selective earth ground rod testing using 1 clamp, stakeless earth ground rod testing using 2 clamps. This ground tester is IP56 rated for outdoor use and comes complete with a rugged carrying case and is capable of USB data storage and transfer.

Kit includes the GEO Earth Ground Tester, 2 clamps, C1620 professional carrying case, 4 earth ground stakes, and 3 cable reels.

• A unique earth ground tester that performs fast, accurate testing with and without stakes

• Tests 3- and 4-pole fall-of-potential, and 4-pole soil resistivity (with stakes)

• Performs selective earth ground rod testing (one clamp + stakes)

• Performs stakeless earth ground rod testing (two clamps)

• Features IP56 rating for outdoor use

Detailed Specifications
General
Display: 1999 Digit LCD	Display with special symbols, digit height 25 mm, fluorescent backlight
User Interface	Instant measurement through TURN and START one button concept. The only operating elements are rotary switch and START button
Robust, Eater and Dust Resistant	Instrument is designed for tough environmental conditions (rubber protective cover, IP56)
Memory	Internal memory storage up to 1500 records accessible via USB port
Temperature Range
Temperature Range	Operating Temperature	-10°C - 50°C (14°F - 122°F)
	Storage Temperature	-30°C - 60°C (-22°F - 140°F)
Temperature Coefficient	+/- 0.1% of reading/°C < 18 °C > 28°C
Intrinsic Error	Refers to the reference temperature range and is guaranteed for 1 y
Operating Error	Refers to the operating temperature range and is guaranteed for 1 y
Climatic Class	C1 (IEC 654-1), -5°C - 45°C (23°F - 115°F), 5% - 95% RH
Protective Type	IP56 for case, IP40 for battery door according to EN60529
