Advanced design, precision construction, compact size, and repeatability; with set points from 0.07 in W.C. to 20 in W.C.

Starting at

$134.70CAD

Some configurations are in stock for immediate delivery!

Have questions? We're here to help!

Call

Configure

Used in

Also found in

1900 Compact Low Differential Pressure Switches 02425

1900 Compact Low Differential Pressure Switches 311a0

1900 Compact Low Differential Pressure Switches 48c2a

1900 Compact Low Differential Pressure Switches 57511

Our most popular Series 1900 combines advanced design and precision construction to make these switches able to perform many of the tasks of larger, costlier units. Designed for air conditioning service, they also serve many fluidics, refrigeration, oven and dryer applications. For air and non-combustible compatible gases, Series 1900 switches have set points from 0.07 in W.C. - 20 in W.C. (1.8 mm - 508 mm). Set point adjustment is easy with range screw located inside conduit enclosure. Internal location helps prevent tampering. UL, CE and CSA listed, and FM approved.

Caution: For use only with air or compatible gases.

• Compact size and repeatability, provides a high-value switch for many industrial and OEM applications
• Wide range of models from 0.07 in W.C. - 20 in W.C. can meet exacting OEM specifications for a low pressure switch
• Range screw protected inside enclosure provides simplifies making adjustments but prevents tampering

Service	Air and non-combustible, compatible gases
Wetted Materials	Consult factory
Temperature Limits	-30°F - 180°F (-34°C - 82.2°C)
Pressure Limits	45 in W.C. (11.2 kPa) continuous, 10 PSIG (68.95 kPa) surge
Switch Type	Single-pole double-throw (SPDT)
Repeatability	± 3%
Electrical Rating	15 A @ 120 VAC - 480 VAC, 60 Hz. Resistive 1/8 HP @ 125 VAC, 1/4 HP @ 250 VAC, 60 Hz. Derate to 10 A for operation at high cycle rates
Electrical Connections	3 screw type, common, normally open and normally closed
Process Connections	1/8 in female NPT
Mounting Orientation	Diaphragm in vertical position. Consult factory for other position orientations
Set Point Adjustment	Screw type inside conduit enclosure
Weight	1 lb 4.5 oz (581 g).
Agency Approvals	CE, CSA, FM, UL. Optional EXPL Explosion-proof enclosure does not possess any agency approvals
