Dwyer

2000-HA Magnehelic Differential Pressure Gage

Indicate Positive, Negative or Differential, Accurate within 1%

Starting at
$132.15CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Configure
Used in
2000 HA Magnehelic Differential Pressure Gage 07603
2000 HA Magnehelic Differential Pressure Gage 0d4e1
2000 HA Magnehelic Differential Pressure Gage 18a7a
2000 HA Magnehelic Differential Pressure Gage 554b5
2000 HA Magnehelic Differential Pressure Gage c04f1
The Series 2000-HA High Accuracy Magnehelic® Gage is twice as accurate as the standard Magnehelic® gage. The well-engineered High Accuracy Magnehelic® Gage offers a mirrored overlay as standard in order to eliminate any parallax error when taking measurements. A six point calibration certificate is included with each high accuracy model. The rugged IP67 casing helps fully protect against dust and water ingress. The redesigned corrosion resistant brushed 304 stainless steel bezel option offers a clean tapered design, yet minimizes the possibility of any dust accumulation on the edges.

NIST CALIBRATION available in Product Configurator.
• Accurate within 1%
• Mirrored scale overlay eliminates parallax error
• Six point calibration certificate included
• IP67 - Fully protects against dust and immersion
• Optional corrosion resistant brushed 304 SS bezel
• See Series 2000 Magnehelic® web page for additional Product Features
Agency Approvals:Meets the technical requirements of EU Directive 2011/65/EU (RoHS II).
Weight:1 lb 2 oz (510 g).
Standard Accessories:Two 1/8" NPT plugs for duplicate pressure taps, two 1/8" pipe thread to rubber tubing adapters, and three flush mounting adapters with screws.
Process Connections:1/8" female NPT duplicate high and low pressure taps – one pair side and one pair back.
Mounting Orientation:Diaphragm in vertical position. Consult factory for other position orientations.
Size:4" (101.6 mm) diameter dial face.
Temperature Limits:20 to 140°F (-6.67 to 60°C).
Overpressure:Relief plug opens at approximately 25 psig (1.72 bar), standard gages only. See Overpressure Protection note on catalog page.
Pressure Limits:-20 in Hg to 15 psig (-0.677 bar to 1.034 bar).
Accuracy:±1% FS (±1.5% on -0, -100PA, -125PA, -10MM and ±2% on -00, -60PA, -6MM ranges) throughout range at 70°F (21.1°C).
Housing:Die cast aluminum case and bezel with acrylic cover. Exterior finish is coated gray to withstand 168 hour salt spray corrosion test.
Wetted Materials:Consult Factory.
Service:Air and non-combustible, compatible gases (natural gas option available). Note: May be used with hydrogen. Order a Buna-N diaphragm. Pressures must be less than 35 psi.
• Clean room positive pressure indication
• Filter monitoring
• Air velocity with Dwyer pitot tube
• Blower vacuum monitoring
• Fan pressure indication
• Duct, room, or building pressures
