Starting at $1,987.83CAD
ConfigureNoshok
30 Series "Snorkel" Press. & Level Transmitters
Ideal for tank level measurement, food & beverage, dairy, breweries, chemical processing & pharmaceutical
Ideal for applications including tank level measurement, food & beverage, dairy, breweries, chemical processing and pharmaceutical.
• 300 Series: ranges from 40 inH2O to 60 psig
301 Series: adjustable ranges from 16 inH2O to 1,450 psig via Hart®
302 Series: adjustable ranges from 40 inH2O to 1,160 psig
304 Series: adjustable ranges from 16 inH2O to 1,450 psig
• Hart® signal output available on 301 & 304 Series Transmitters
• 316 Stainless Steel wetted parts
• Strong flush diaphragm with minimal fill volume
• Can be cleaned-in-place (CIP) or steamed-in-place (SIP)
• 3A Certified
• 300/301 Series
• Cable connection only (no housing)
• Active temperature compensation
• Fixed range (300 Series)
• Range adjustment with Hart® (301 Series) 302 Series
• All polished Stainless Steel housing
• Active temperature compensation
• Zero/span adjustable
• 10:1 Turn down (301 Series)
• 302 Series
• All polished Stainless Steel housing
• Active temperature compensation
• Zero/span adjustable
• 4:1 Turn down
• 304 Series
• All polished Stainless Steel housing
• Active temperature compensation
• Accuracy 0.1% of adjusted span
• 10:1 Turn down
• Easy programming and range adjustment without test pressure via on-board display
• Hart® protocol available
• Tank level measurement
• Food & Beverage
• Dairy
• Breweries
• Chemical processing
• Pharmaceutical
![Thumbnail of document Data Sheet - 30 Series "Snorkel" Press. & Level Transmitters](https://alpha-controls.files.svdcdn.com/transforms/productdownloads/30 Series "Snorkel" Press. & Level Transmitters/333951/30-Series-SNORKEL-Pressure-and-Level-Transmitter_13818_1-72_5f28a37dfffeac17d8504dfc1bc3d34b.png)
