Amprobe

35XP-A Digital Multimeter with Temperature

Offers all the right features for HVAC and plant maintenance, measuring temperature and capacitance

Buy now!
$349.99CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
35 XP A Digital Multimeter with Temperature 03912

The compact 35XP-A Digital Multimeter offers all the right features for HVAC and plant maintenance. It measures temperature, plus capacitance for motor run/start test, and offers 0.1 µA resolution for flame sensor testing.

The 35XP-A comes with one (1) pair of test leads, temperature adapter, K-Type thermocouple probe, one (1) 9 V battery (installed), user's manual, Magne-Grip holder with hanging strap, and a carrying case.



• Temperature measurement capability to 1000°C (1832°F) (K-Type thermocouple probe included)
• 600 V AC/600 V DC - highest voltage rating in this class of meter
• Capacitance for motor run/start test
• 0.1 μA resolution for flame sensor testing
• Frequency to 1 MHz
• Resistance to 40 MΩ
• Data hold freezes display
• Magne-Grip™ Holster
• VolTect™ non-contact voltage detector
• Low battery indication

Overload protection 600 V DC or 600 V AC RMS
Open circuit voltage -0.45 V DC typical, (-1.2 V DC on 400 Ω range)
Resistance resolution 100 mΩ
Resistance 40 MΩ ± (2.0 % rdg + 5 dgts)
Resistance 400 Ω , 4 kΩ , 40 kΩ , 400 kΩ , 4 MΩ ± (1.0 % rdg + 4 dgts)
Burden voltage 500 mV max. (2 V max. on 4 mA, 400 mA ranges)
Input protection 2 A/1000 V fast blow ceramic fuse 6.3 mm x 32 mm on A input
Current resolution 0.1 µA
AC Current (45 Hz to 500 Hz) range 2 A ± (2.5 % rdg + 5 dgts)
AC Current (45 Hz to 500 Hz) range 400 µA, 4000 µA, 40 mA, 400 mA ± (1.5 % rdg + 5 dgts)
DC Current range 2 A ± (2.0 % rdg + 3 dgts)
DC Current range 400 µA, 4000 µA, 40 mA, 400 mA ± (1.0 % rdg + 2 dgt)
Overload protection 600 V DC or 60 V AC RMS
Input impedance 400 mV: >100 MΩ ; 4 V: 10 MΩ ; 40 V to 600 V: 9.1 MΩ
Voltage resolution 100 µV
AC Volts (45 Hz to 500 Hz) range 400 mV (45 Hz to 100 Hz)
4 V, 40 V, 400 V, 600 V (45 Hz to 500Hz)
Accuracy: ± (1.5 % rdg + 5 dgts)
DC Volts range 400 mV, 4 V, 40 V, 400 V, 600 V
Accuracy: ± (0.5 % rdg + 1 dgts)
Battery test –
Logic test –
Temperature -4 °F → 1832 °F (-20 °C → 1000 °C)
Frequency 4,000 kHz, 40.00 kHz, 400,0 kHz, 1 MHz
Capacitance 4.000 nF, 40.00 nF, 4.000 µF, 40.00 µF, 400.0 µF, 4.000 mF
VolTect™ Non-Contact Voltage Detection 70 V AC → 600 V AC (50 Hz → 60 Hz)
Continuity beeper ✓
Resistance 40.00 kΩ, 400.0 kΩ, 4.000 MΩ. 40.00 MΩ
Current AC/DC 400.0 µA, 4.000 µA, 40.00 mA, 400.0 mA, 2 A
AC Voltage 400.0 mV, 4.000 V, 40.00 V, 400.0 V, 600 V
DC Voltage 400.0 mV, 4.000 V, 40.00 V, 400.0 V, 600 V





  • Thumbnail of document Data Sheet - 35XP-A Digital Multimeter with Temperature
    Download

    Data Sheet - 35XP-A Digital Multimeter with Temperature

    Download
  • Thumbnail of document Manual - 35XP-A Digital Multimeter with Temperature
    Download

    Manual - 35XP-A Digital Multimeter with Temperature

    Download
