525B Thermocouple & RTD Calibrator

Name: 525B Thermocouple & RTD Calibrator
SKU: placeholder-525b-thermocouple-rtd-calibrator
Price: 3175.95 CAD
Availability: InStock

Automated, high accuracy meter calibrates multiple thermocouple and RTD types

Buy now!

$3,175.95CAD

Have questions? We're here to help!

Call

QTY

Used in

PIE is pleased to introduce the New Model 525B which replaces the PIE Model 525. This moves their Dual Thermocouple & RTD calibrator to the PIE Evolution enclosure with a rubber boot, tilt stand, 4 “AA” batteries and backlit display. Not only did they move the product into the new enclosure, they also made a number of other improvements:

• Increased number of T/C types from 10 to 14
• Added RTD types for Platinum 10, 50, 200 & 500 Ohm for the 1.3850 (IEC 751/DIN) curve
• More accurate & stable cold junction compensation
• Secondary display
• Troubleshoot RTD Sensors & Instruments

• Calibrate T/C instruments to 0.1 & 0.01 °F & °C
- Types J, K, T, E, R, S, B, N, G, C, D, L (J DIN), U (T DIN) & P (Platinel): -13.000 to 80.000 mV
• Calibrate RTD instruments to 0.1 & 0.01 °F & °C
- Pt 10, 50, 100, 200, 500 & 1000 Ohm (3850)
- Pt 100 Ohm (alpha=3902, 3916, 3926)
- Cu 10 & 50 Ohm and Ni 120 Ohm

• Calibrate with Confidence
• Perform Heat Treating Surveys & Accuracy Tests
• Troubleshoot RTD Sensors & Instruments
• Faster Calibrations
• Easily Change T/C Types & Scale
• Use in the Plant, Field or Shop
• Easy-to-Read Display
• Simple "No Tool" Battery Changes
• Verify Resistance, Cold Junction Temperature & Output
