A/RH1-TTM1K-RP2-10-4X-4 RH Remote Probes
Relative Humidity, Remote Probe, 10' Plenum, NEMA 4X Enclosure, Transmitter w/ 1,000 Ohm RTD, 4-20mA
This product is no longer available. Contact us at 800-567-8686 for alternative solutions.
The ACI Relative Humidity with Temperature Transmitter Series Remote Probe utilizes a thermoset polymer capacitive sensing element with a hydrophobic filter to deliver a proportional relative humidity analog output. All models feature conformally coated circuit boards to improve the reliability of the product in both high moisture and mildly corrosive atmospheres. The standard enclosure is an IP66/NEMA 4X rated moisture and corrosion resistant enclosure. A vinyl cap is provided to place over the sintered filter in applications in wash down applications to protect the sensing element from getting moisture sprayed directly on the sensor. NIST Calibration Certificates (Temperature and RH) are included for all TTM RH part series.
