ACD-51NAV CAT IV 600A True-RMS Navigator™
Clamp-on power meter offers a full range of diagnostics, including voltage, current, resistance, capacitance, & temperature
This product is no longer available. Contact us at 800-567-8686 for alternative solutions.
This versatile clamp-on power meter offers a full range of diagnostics, including those that HVAC technicians need most—volts, amps, resistance, capacitance, DC microamps, in-rush current and temperature.
A great clamp-on multimeter choice for troubleshooting or maintaining air conditioning or motor efficiency, measuring phase rotation, and identifying harmonics. Convenient joystick enables quick single-handed function selection.
The ACD-51NAV includes test leads, banana K-type thermocouple, one (1) 9 V battery (installed), user's manual, and a deluxe carrying case.
• True-RMS technology improves accuracy in noisy environments
• Measures AC/DC voltage to 1000 V, AC current to 600 A, plus resistance, frequency, capacitance, power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25
• Measures temperature from -58°F to 1832°F (-50°C to 1000°C)
• Provides DC micro amps measurements to test flame sensors
• Includes inrush current measurement and phase rotation indication for 3-phase motors
• Non-contact voltage detection enhances safety
• Low pass filter enables measuring voltage and frequency on variable frequency drives
• Continuity beeper quickly identifies shorts and opens
• Large backlit digital display with analog bar graph presents the full picture
• Min, max and smart data hold
• Peak hold identifies spikes and transients
• In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes
• Auto power off conserves battery life
• Maximum jaw opening accommodates large conductors up to 1.45 in (37 mm)
• Rubber overmold body absorbs shocks — drop proof to 4 ft (1.2 m)
• CAT IV-rated
• Includes test leads, batteries (installed), deluxe carrying case, banana k-type thermocouple and user's manual
