ACD-53NAV CAT IV 1000 A AC True-RMS Navigator™ Clamp Meter
Clamp-on power meter offers AC current, AC/DC voltage measurements, & extra large jaws to handle large conductors
This product is no longer available. Contact us at 800-567-8686 for alternative solutions.
The ACD-53NAV AC current clamp meter offers AC current measurements to 1000 A, AC/DC voltage to 1000 V, and extra large jaws to accommodate conductors up to 1.6 in (40 mm) in diameter.
This clamp-on multimeter offers a full range of power quality diagnostics including power and power factor, total harmonics distortion, individual harmonics, in-rush current, phase sequence, TRMS and low pass filter for industrial power monitoring and verifying system conditions.
The ACD-53NAV current clamp comes with test leads, one (1) 9 V battery (installed), user's manual, and a deluxe carrying case.
• True-RMS technology improves accuracy in noisy environments
• Measures AC/DC voltage to 1000 V, AC/DC current to 600 A, plus resistance, frequency, capacitance, power and power factor, total harmonics distortion (THD) and individual harmonics from 1 to 25
• Includes inrush current measurement and phase rotation indication for 3-phase motors
• Non-contact voltage detection enhances safety
• Low pass filter enables measuring voltage and frequency on variable frequency drives
• Continuity beeper quickly identifies shorts and opens
• Large backlit digital display with analog bar graph presents the full picture
• Min, max and smart data hold
• Peak hold identifies spikes and transients
• In-jaw flashlight automatically lights when jaws open to illuminate dark panels and junction boxes
• Auto power off conserves battery life
• Maximum jaw opening accommodates large conductors up to 1.45 in (37 mm)
• Rubber overmold body absorbs shocks — drop proof to 4 ft (1.2 m)
• CAT IV-rated AC/DC current clamp meter
• Includes test leads, batteries (installed), deluxe carrying case, and user's manual
