BioCapt® Microbial Impactor
Enables the capture of microbiologically viable particulates on a suitable media surface for later incubation and enumeration
BioCapt® is a microbial air sampler designed to accurately capture viable airborne contaminants for environmental monitoring. Get the best solution for your application with four models available.
• Available in stainless steel or single use models
• Meets ISO 14698 and ISO 17141
• Unique radial slit design to increase efficiency
• Optimize processes with minimal air disruption
• Increase uptime with fast troubleshooting
Single-Use
The BioCapt® Single-Use Microbial Impactor is a lightweight, integrated air sampler designed for use with both portable and remote monitoring systems in remote sampling environments. Its single-use design reduces the risk of false positives and final product contamination associated with microbial sampling, while lowering investigation costs and avoiding non- conclusive results from traditional agar settle plates.
The innovative impactor design combines the media plate and sampling head into a single sterile, ready-to-use unit prefilled with medium, eliminating agar preparation, autoclaving, and stainless-steel head disinfection. Each unit minimizes handling and is supplied gamma-irradiated and double-bagged, with three units per package.
The single use impactor uses a radial slit design, validated at the Centre for Applied Microbiology & Research (CAMR), a Health Protection Agency (HPA) at Porton Down. It achieves isokinetic sampling for minimal air turbulence in compliance with ISO 146981 and can be used for sampling at 25 - 50 LPM.
Potential for handling-related contamination is reduced through a simple process: the impactor is removed from the bag, installed in a portable or continuous monitoring system, and opened for sampling. After sampling, the lid is replaced and the unit is placed directly into the incubator. The lightweight design allows for easy one-handed operation.
Single-Use
- Test ready
- Fully prepared and disposable
- Eliminates agar plate preparation
- Sample efficiently at 25 or 50 LPM
- False-positive reduction
- Minimizes operator handling
- Eliminated unintended contamination
- Each set of three samplers is double-bagged and gamma irradiated
- Cost reduction and increased productivity
- Higher quality assurance through continuous monitoring (up to 4 hours)
- Eliminates time-consuming and operator-dependent steps such as disinfection, sanitization, and sterilization
- Eliminates uncertainty from settle plate results
- Risk reduction during the introduction and withdrawal of microbiological sampling plates in sterile production areas
- Culture media stability validated up to 12 months
- Storage at room temperature or under refrigeration
- Improved lot traceability with three-dimensional QR codes
- Compatible with active air monitoring systems
- Extensive validation studies
- 100% inspection of critical dimensions during manufacturing process
- Leakage test ensuring perfect assembly
- Complies with ISO 14698-1 for highest microbiological and physical efficiencies
- Proven recovery of microorganisms under stressed conditions after 2 hours of continuous air sampling (25 LPM flow rates)
- Standard culture media of TSA and SDA
Single-Use
- Microbial air sampling monitoring in controlled environments
- USP 797 environmental viable airborne particle testing
- Microbial monitoring of critical control points in aseptic manufacturing areas (Isolators, RABS, ISO 5/Class A)
