CL515-Plus High Accuracy RTD Auto-Connect Display Calibrator & Thermometer

Universal RTD Calibrator

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
CL515 Plus High Accuracy RTD Auto Connect Display Calibrator Thermometer 09179

 With the CL515-PLUS you can check and calibrate all your RTD instruments and measure RTD Sensors. Automatic indication of connections on the display for simple hookups.


Stop carrying around a decade box and RTD resistance tables. The CL515-PLUS works with the RTDs you use including Platinum 100 (alpha = 3850, 3902, 3926) & 1000 (alpha = 3850, 3750) Ohm, Copper 10 & 50 Ohm, Nickel 100 and 120 Ohm. Easily set any value quickly to within 0.1° with the adjustable digital potentiometer “DIAL” plus store any three temperatures for instant recall with the check switch.

Calibrate quickly with automatic output stepping, choose between 2, 3, 5, 11 and 21 steps to automatically increment the output in 100%, 50%, 25%, 10% or 5% of span. Select the step time to match your system from 5, 6, 7, 8, 10, 15, 20, 25, 30 and 60 seconds.

Carry it without worry—it comes protected with a rubber boot and rugged, low profile switch. Easy to operate even in the dark areas of the plant with the backlit display.
• Easy to Use
• Calibrate and Measure Most RTD Sensors
• Comes Protected With a Rugged Rubber Boot
• Calibrate Directly in Temperature (ºC or ºF)
Specifications(Unless otherwise indicated all specifications are rated from a nominal 23°C, 70% RH for 1 year from calibration)
Accuracy±(0.015% of Reading + 0.05 ?)
Temperature Drift± 0.01% of span outside of 23°C ±10°C (73°C ±18°F) Operating Temperature
Range-25 to 60°C (-10 to 140°F)
Relative Humidity Range10% ?RH ?90% (0 to 35°C), non-condensing, 10% ?RH ?70% (35 to 60°C), non-condensing
Dimensions143 L x 76 W x 41 mmH (5.63 x 3.00 x 1.60")
Weight0.34 kg (12.1 oz) including boot and batteries
Power4 "AA" Alkaline 1.5V (LR6) (included)
Battery Life50 Hours low Battery low battery indication with nominal 1 hour of operation left. Protection against misconnection over-voltage protection to 60 Vdc (rated for 30 seconds)
DisplayHigh contrast graphic liquid crystal display. LED backlighting for use in low lit areas.
Read
ExcitationCurrent 0.5 mA nominal
Normal Mode Rejection50/60 Hz, 50 dB
Common Mode Rejection50/60 Hz, 120 dB
Source
AccuracyFrom 1 to 10.2 mA external excitation Current ± (0.015% of Reading + 0.05 ?)
Below1 mA of external excitation
Current± (0.015% of reading + 0.025 mV/mA excitation current + 0.05 ?)
Resistance Ranges0.00 to 410.00, 410.1 to 4001.0 ?
Allowable Excitation Current Range<410 Ohms: 10.2 mA max; steady or pulsed/intermittent
410 to 4001 Ohms: 1 mA max; steady or pulsed/intermittent
Pulsed ExcitationCurrent compatibility DC to 0.01 second pulse width 0.025 mV
  • Thumbnail of document Manual - CL515-Plus High Accuracy RTD Auto-Connect Display Calibrator & Thermometer
