Amprobe

CO2-200 Wall-Mounted CO2 Meter

Low drift wall mounted carbon dioxide meter for measuring indoor air quality

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!
Have questions? We're here to help!

Instant feedback with CO2 levels, with additional temperature and humidity measurements. Built in alarm to warn against dangerous CO2 levels. The permanent mounted CO2-200 Air Quality Meter is designed to measure air quality compliance in critical environment controlled areas such as laboratories and production.

The CO2-200 CO2 meter comes with a power adapter (110 V - 240 V AC), user's manual, and carrying case.





• Super-large LCD display with CO2 reading
• CO2 measurement up to 9999 ppm, temperature, relative humidity, dew point and wet bulb
• Super-large LCD display with CO2 reading
• High performance low drift sensor designed with NDIR (non-dispersive infrared) waveguide technology with automatic background calibration
• Audible alarm threshold setting to setup warning against carbon dioxide level with output drive relay to control air flow system
• Optional PC download capabilities (USB interface) data hold
• Recording of maximum, minimum and average values with recall function
• Meter, manual, power adapter 100 - 240 V AC



CO2-100

CO2-200

CO2

0 - 9999 ppm

0 - 9999 ppm

Accuracy

± 30 ppm ± 5% of reading (CO2) (0 - 5000 ppm)

other range accuracies are not specified

± 75 ppm ± 5% of reading (0 - 2000 ppm)

other range accuracies are not specified

Temperature Range

14°F - 140°F (-10°C - 60°C )

14°F - 140°F (-10°C - 60°C)

Temperature Accuracy

± 0.6°C (± 0.9°F)

RH Range

0% - 95%

0% - 95%

RH Accuracy

± 3% RH (at 25°C, 10% - 90%)

± 5% for other RH range

DP (Dew Point Temperature)

-4°F - 139.8°F (-20°C - 59.9°C)

-4°F - 139.8°F (-20°C - 59.9°C)

WB (Wet Bulb Temperature)

24.8°F - 139.8°F (-5.0°C - 59.9°C)

23°F - 139.8°F (-5.0°C - 59.9°C)

Resolution

1 ppm - CO2 concentration, 0.1°C (0.2°F) - Temp, 0.1% RH - humidity

1 ppm - CO2 concentration, 0.1°C (0.2°F) - Temp, 0.1% RH - humidity

Power Supply

12 V DC adaptor

<

  • Thumbnail of document Data Sheet - CO2-200 Wall-Mounted CO2 Meter
    Download

    Data Sheet - CO2-200 Wall-Mounted CO2 Meter

    Download
  • Thumbnail of document Manual - CO2-200 Wall-Mounted CO2 Meter
    Download

    Manual - CO2-200 Wall-Mounted CO2 Meter

    Download
