D1300 Thermocouple Input Modules

Module converts thermocouple temp. sensor input signals, linearizes the digital data, scales in degrees C/F & communicates the values to a host

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Also found in
D1300 Thermocouple Input Modules 00594

The D1300 ADC module converts thermocouple temperature sensor input signals to digital information, linearizes the digital data, scales in either degrees C or F, and communicates the values to a host computer or PLC. The data values are transmitted in ASCII  to a host computer via RS232 or RS485.

The D1300 series modules can also be mounted on a DIN-Rail using the MK-1 mounting kit.

TypesJ, K, T, E, R, S, B, C
Accuracy (errors from all sources) from 0 to + 40°C ambient+/- 1 °C max (J,K,T,E types). +/- 2.5 °C max for (R,S,B,C types)
Resolution1°(C or F)
Common Mode Rejection100 db at 50/60 Hz.
User Selectable Degrees C or F scaling
Lead Resistance Effect< 20 µV per 350 Ω
Input Burnout Protection To 250 VAC
Input Impedance100 MΩ min
Thermocouple Measurement RangesJ = -200 to +760°C
B = 0 to +1820°C
K = -150 to +1250°C
S = 0 to +1750°C
T = -200 to +400°C
R = 0 to +1750°C
E = -100 to +1000°C
C = 0 to +2315°C
  • Thumbnail of document Data Sheet - D1300 Thermocouple Input Modules
    Download

    Data Sheet - D1300 Thermocouple Input Modules

    Download
  • Thumbnail of document Manual - D1300 Thermocouple Input Modules
    Download

    Manual - D1300 Thermocouple Input Modules

    Download
