DGH

D5200 Current Input Module

Convert up to four 4 - 20 mA analog DC current input signals, linearizes the digital data & communicates the values to a host computer or PLC

This product is no longer available. Contact us at 800-567-8686 for alternative solutions.

Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Also found in
D5200 Current Input Module 00647
D5200 2

The DGH D5200 ADC current input modules convert up to four 4-20mA analog DC current input signals to digital information, linearizes the digital data and communicates the values to a host computer or PLC.

The data values are transmitted to a host computer via an RS232 or RS485 serial communications link using an ASCII protocol.

The D5200 series current input modules can be mounted on a DIN-Rail using the MK-1 mounting kit.

Range4-20 mA (0-25 mA full scale)
Accuracy+/- 0.04% of F.S.
Resolution0.01% of F.S.
Common Mode Rejection100 db at 50/60 Hz
Zero Drift+/- 1 count max (autozero)
Span Tempco+/- 50 ppm/°C max
Voltage Drop< 1.25 V
  • Thumbnail of document Data Sheet - D5200 Current Input Module
    Download

    Data Sheet - D5200 Current Input Module

    Download
  • Thumbnail of document Manual - D5200 Current Input Module
    Download

    Manual - D5200 Current Input Module

    Download
