DHII Digihelic Differential Pressure Controller

Name: DHII Digihelic Differential Pressure Controller
SKU: placeholder-dhii-digihelic-differential-pressure-controller
Price: 1761.60 CAD
Availability: InStock

NEMA 4 housing with large & bright LCD, detachable terminal blocks reduce wiring difficulties

Starting at

$1,761.60CAD

Have questions? We're here to help!

Call

Configure

Used in

Also found in

DHII Digihelic Differential Pressure Controller 02371 xl

The Series DHII takes all the fabulous features of the standard Digihelic® Pressure Controller and packages them in a robust NEMA 4 (IP66) housing.

The Digihelic® II Pressure Controller combines the 2 SPDT control relays, 4 - 20 mA process output and Modbus communications with a large, brightly backlit 4 digit LCD display that can easily be seen from long distances. The electrical wiring has also been enhanced in the DHII with its detachable terminal blocks. The removable terminals allow the install to easily wire the terminal block outside the housing and then attach to the circuit board, reducing wiring difficulties and installation time on the process.

The Digihelic® II Differential Pressure Control in the new NEMA 4 (IP66) enclosure enables this product to be the perfect choice when mounting pressure controls outdoors in such applications as rooftop air handlers. This housing also makes it the ideal solution for surface mounting in clean rooms or facilities where water or a cleaning solution is utilized in maintaining plant cleanliness.

• NEMA 4 housing enables a range of uses both outdoors or indoors where water is present
• Large backlight LCD display provides local reading from a distance
• Detachable terminal blocks reduce wiring difficulties saving installation time

Service	Air and non-combustible, compatible gases
Wetted Materials	Consult factory
Housing Material	Aluminum, glass
Accuracy	± 0.5% at 77°F (25°C) including hysteresis and repeatability (after 1 hour warmup)
Stability	< ± 1% per year
Pressure Limits	Ranges ≤ 2.5 in W.C. = 2 PSI; 5 in: 5 PSI; 10 in: 5 PSI; 25 in: 5 PSI; 50 in: 5 PSI, 100 in: 9 PSI
Temperature Limits	32°F - 140°F (0°C - 60°C)
Compensated Temperature Limits	32°F - 140°F (0°C - 60°C)
Thermal Effects	0.020%/°F (0.036/°C) from 77°F (25°C)
Power Requirements	High voltage power = 100 VAC - 240 VAC, 50 Hz - 400 Hz or 132 VDC - 240 VDC; Low voltage power = 24 VDC ± 20%
Power Consumption	Low voltage power = 24 VDC - 130 mA max; High voltage power = 100 VAC - 240 VAC, 132 VDC - 240 VDC - 7 VA max
Output Signal	4 - 20 mA DC into 900 Ω max
Zero & Span Adjustments	Accessible via menus
Response Time	250 ms (dampening set to 1)
Display	4 digit backlit LCD 0.6 in height. LED indicators for set point and alarm status
Electrical Connections	Euro type removable terminal blocks with watertight conduit fittings for 1/2 in watertight conduit
Process Connections	1/8 in female NPT
Enclosure Rating	Designed to meet NEMA 4 (IP66)
Mounting Orientation	Mount unit in horizontal plane
Weight	2 lb 10 oz (1.19 kg)
Serial Communications	Modbus® RTU, RS485, 9600 Baud
Agency Approvals	CE, UL
SWITCH SPECIFICATIONS
Switch Type	2 SPDT relays
Electrical Rating	8 A @ 240 VAC resistive
Set Point Adjustment	Adjustable via keypad on face
