Buy now! $173.87CAD
Lascar

EL-USB-4 Current Data Logger with USB

Current data logger with USB

Buy now!
$173.87CAD
Have questions? We're here to help!
Have questions? We're here to help!
Call
Email
Used in
EL USB 4 Current Data Logger with USB 00461
Easylog data logger EL USB 4 Angle Lid Off 2
Easylog data logger EL USB 4 in PC

This standalone data logger measures more than 32,000 readings over a 4 - 20 mADC measurement range. The data logger is supplied with a cap featuring a pair of screw terminals and measurement leads terminating in crocodile clips. Easily set up the logger and view downloaded data by plugging the unit into a PC’s USB port and using the free EasyLog software provided. Data can then be graphed, printed and exported to other applications for detailed analysis. Supplied with 1/2 AA battery and wall mount clip.

• 4 - 20 mADC current loop measurement range
• Stores over 32,000 readings
• Logging rates between 1 second and 12 hours
• Connection via two screw terminals
• Immediate and delayed logging start
• User-programmable alarm thresholds
• Status indication via red and green LEDs
• EasyLog software available as a free download

Measurement Range4 to 20mA d.c.
Internal Resolution0.05mA d.c.
Accuracy (Overall Error)+/- 1%
Input Impedance110 Ohms
Logging RateUser selectable between 1 second and 12 hours
Operating Temperature Range-35 to +80°C (-31 to +176°F)
Battery Life3 Years (at 25°C and 2 second logging rate)
Readings32,510
Dimensions98 x 26.8 x 26.8 mm (3.85 x 1.05 x 1.05”)

• Outside Environmental Data

  • Thumbnail of document Guide - EL-USB-4 Current Data Logger with USB
    Download

    Guide - EL-USB-4 Current Data Logger with USB

    Download
  • Thumbnail of document Data Sheet - EL-USB-4 Current Data Logger with USB
    Download

    Data Sheet - EL-USB-4 Current Data Logger with USB

    Download
