Flintec RC3 Stainless Steel Rocker Column Load Cell 10923

 Rocker designed and provides superior performance and full hermetic design in applications in moist and high humidity environments. Constructed of stainless steel. Available in capacities from 7.5t to 50t.

ApprovalsFM
NTEP
OIML
WarrantyOne-year limited
Cable Color CodeGreen +ExcitatIon
Black –Excitation
White +Signal
Red –Signal
Yellow Shield
Cable Diameter0.307 in
Polyurethane jacket
Cable Length7.5 to 22.5 t: 40 ft
30 to 50 t: 18 m
Insulation Resistance5,000 megohm
Combined Error0.02% full scale
Rated Excitation5 to 10 VDC (15 V maximum)
Safe Sideload200% full scale
Safe Overload200% full scale
Seal TypeHermetically sealed, IP69K
TemperatureCompensated range
14 °F to 104 °F (-10 °C to 40 °C)
Operating range
0 °F to 150 °F (-18 °C to 65 °C)
Material/FinishStainless steel
Input Resistance1,150 (± 50) ohm
Output Resistance1,000 (± 2) ohm
Full Scale Output2.0 mV/V
mV/V/ohm calibration
  • Thumbnail of document Data Sheet - Flintec RC3 Stainless Steel, Rocker Column Load Cell
    Download

    Data Sheet - Flintec RC3 Stainless Steel, Rocker Column Load Cell

    Download
